Alarm.Com ADC-V510 Installation Manual

Install the Camera(s):

1. Use a standard Ethernet cable (not included) to
connect the camera to the network router. Then
connect the camera's AC adapter and plug it into
a non-switched outlet. (See illustration to right.)
2. From a PC connected to the same network, log into
the customer's Alarm.com account using Internet
Explorer.
3. After logging in, type
into the browser's address bar.
If prompted by the browser, download the ActiveX
4.
control. (Note that some corporate PCs allow only
administrators to download ActiveX controls.)
5. Once the camera has been detected, select it from the list of available cameras and follow the on-screen instructions to add
it to the Alarm.com account.
6. If the camera will be connected wirelessly to the network: To configure the camera's wireless settings when setup is
complete, click on the Configure wireless network settings for this camera link and follow the on-screen instructions.
Note: When adding additional cameras, make sure to leave the initial camera(s) connected to the network.
Questions? Contact Alarm.com Dealer Support at 1.866.834.0470 or support@alarm.com.

Required Items for Installation:

•
•
•
•
•
•
•
•
NOTE: For commercial facilities, make sure an IT staff member is available to
www.alarm.com/addcamera
Camera Installation Guide
ADC-V510 camera and power adapter (included)
Broadband (Cable, DSL, or Fiber-optic) Internet connection
Network router (or a modem with built-in router)
Login/password for the customer's Alarm.com account
A Windows PC with Internet Explorer
Ethernet cable for the camera
If the camera will be connected to a wireless network, you will need:
- the case-sensitive SSID (wireless network name)
- the network WEP or WPA key (if encryption is enabled at the router)
In addition to the above items, you may also need:
- the network router's login and password, if Universal Plug and Play
(UPnP) is disabled at the router
- A spare Ethernet cable, if the PC you are using for setup is not already
connected to the network and is not able to be connected wirelessly
Model: ADC-V510
Alarm.com, Inc. © 2000-2008 All Rights Reserved
