3, Module test.copying the following code to the IDE compiler environment (you can also open the
program directly in the CD), downloading it to the development board, opening the serial port monitor (baud
rate is 9600) and observing the changes of data when there is a obstacle (Figure 3.2.11) and no obstacle (Figure
3.2.12).
Note: Here we connect the infrared obstacle avoidance signal output port to the analog port on Arduino
(A0-A5), so the serial port prints out analog value, you can connect it to digital port (2-13), and the serial port
will only print out "0" and "1".
const int leftPin
const int rightPin
int dl;
int dr;
void setup()
{
Serial.begin(9600);
pinMode(leftPin, INPUT);
pinMode(rightPin, INPUT);
delay(1000);
}
void loop()
{
dl = analogRead(leftPin);
dr = analogRead(rightPin);
Serial.print("left:");
Serial.print(dl);
Serial.print("
Serial.print("right:");
Serial.println(dr);
}
= A3;
= A4;
");
