Specifications

Install the capture device

1. Connect an HDMI cable (included) to the output port on your video source device
and to the HDMI In port on the capture device.
2. Connect the USB cable (included) to the USB port on the capture device, and to a
USB port on your computer.
3. Your computer automatically installs the necessary drivers, when the capture device
is connected.
4. (Optional) To preview the video source that's being sent through the capture device,
connect an HDMI cable (sold separately) to the HDMI Out port on the capture
device and to an HDMI display.
5. (Optional) To add an additional audio source to the signal for capture, connect a 3.5
mm audio cable (sold separately) to the audio output port on your audio source
device and to the Audio In port on the capture device.
Instruction Manual
UVC Output Resolution
USB 3.0
1920×1200p@60/50/30/25/24fps
1920×1080p@60/50/30/25/24fps
1280×1024p@60/50/30/25/24fps
1280×720p@60/50/30/25/24fps
1024×768p@60/50/30/25/24fps
800×600p@60/50/30/25/24fps
640×480p@60/50/30/25/24fps
720×576p@60/50/30/25/24fps
720×480p@60/50/30/25/24fps
