StarTech.com UVCHDCAP Quick Start Manual

USB-C Capture Device for HDMI Video - 1080p - Windows and Mac
Product ID (UVCHDCAP)
Product Diagram
Front View
Back View
USB
port
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
*Product may vary from images
HDMI Audio
In In
port port
HDMI Out
port
Product Information & Requirements
For the latest drivers, software, manuals, product information, technical specifications,
and declarations of conformance, please visit:
www.StarTech.com/UVCHDCAP
• HDMI video source with cabling x 1
• HDMI display with cabling (optional for video passthrough) x 1
Package Contents
• Capture device x 1
• USB-C to USB-B cable (1m) x 1
• USB-A to USB-B cable (1m) x 1
• HDMI cable (1m) x 1
• Quick-Start Guide x 1
Installation
Driver Installation
Navigate to www.StarTech.com/UVCHDCAP
locate and download the latest Driver.
Software Installation
Navigate to www.StarTech.com/UVCHDCAP
tab to locate and download the latest Windows Video Capture Software and the
accompanying Software User Guide.
Install the capture device
1. Connect an HDMI cable (included) to the output port on your video source device
and to the HDMI In port on the capture device.
2. Connect the USB cable (included) to the USB port on the capture device, and to a
USB port on your computer.
3. Your computer automatically installs the necessary drivers, when the capture device
is connected.
4. (Optional) To preview the video source that's being sent through the capture device,
connect an HDMI cable (sold separately) to the HDMI Out port on the capture device
and to an HDMI display.
Quick-Start Guide
and select the Drivers/Downloads tab to
and select the Drivers/Downloads
Manual Revision: May 20, 2021 5:18 PM
