StarTech.com USB32HDCAPRO Quick Start Manual

USB 3.0 Capture Device for HDMI® Video
Product ID (USB32HDCAPRO)
Product Diagram
Front View
Back View
USB
port
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
HDMI Audio
In In
*Product may vary from images
port port
HDMI Out
port
*Product may vary from images
Product Information & Requirements
For the latest drivers, software, manuals, product information, technical specifications,
and declarations of conformance, please visit:
www.StarTech.com/USB32HDCAPRO
• HDMI video source with cabling x 1
• HDMI display with cabling (optional for video passthrough) x 1
Package Contents
• USB 3.0 capture device for HDMI video x 1
• 3.3 ft [1 m] USB 3.0 cable x 1
• 3.3 ft [1 m] HDMI cable x 1
• Quick-Start Guide x 1
Installation
Driver Installation
Navigate to www.StarTech.com/USB32HDCAPRO
tab to locate and download the latest Driver.
Software Installation
Navigate to www.StarTech.com/USB32HDCAPRO
tab to locate and download the latest Windows Video Capture Software and the
accompanying Software User Guide.
Hardware installation
To use the video adapter in USB mode, ensure the software installation steps
have been completed before you connect the adapter to your computer.
1. Connect an HDMI cable (sold separately) to the output port on your video source
device and to the video adapter's HDMI In port.
2. Connect the included USB cable to the video adapter's USB port, and to a USB port
on your computer system.
3. Your computer will automatically detect the USB drivers for the video adapter and
install them.
4. To preview the video source that's being sent through the capture device, by
connecting an HDMI cable (not included) to the video adapter's HDMI Out port and
to an HDMI display.
Quick-Start Guide
and select the Drivers/Downloads
and select the Drivers/Downloads
Manual Revision: May 20, 2021 7:17 PM
