Introduction; Prior To Installation; Resources Required - Lippert Components Solera Installation And Owner's Manual

Introduction

The Solera Power Awning features an internal motor
®
to steadily operate the awning. Additionally, the pitch
arm assembly allows for rain dump and adjustable pitch
features. The pitch arm assembly also provides added
stability.
Additional information about this product can be obtained
from lci1.com/support or by downloading the free
myLCIapp. The app is available on iTunes
iPad and also on Google Play
®
iTunes , iPhone and iPad
® ®
of Apple Inc.
Google Play and Android
™
of Google Inc.
THIS MANUAL PROVIDES OPERATIONAL
PROCEDURES FOR THE SOLERA POWER AWNING.
OPERATING THE SOLERA POWER AWNING IN
ANY OTHER MANNER THAN DESCRIBED MAY
RESULT IN PERSONAL INJURY, DAMAGE TO THE
RECREATIONAL VEHICLE UNIT OR THE AWNING
ASSEMBLY AS WELL AS VOIDING THE LIPPERT
COMPONENTS LIMITED WARRANTY.
THE "WARNING" SYMBOL ABOVE IS A SIGN THAT
AN INSTALLATION PROCEDURE HAS A SAFETY
RISK INVOLVED AND MAY CAUSE DEATH OR
SERIOUS INJURY IF NOT PERFORMED SAFELY AND
WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL. ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING THIS INSTALLATION PROCEDURE.
OTHER SAFETY EQUIPMENT TO CONSIDER
WOULD BE HEARING PROTECTION, GLOVES, AND
POSSIBLY A FULL FACE SHIELD, DEPENDING ON
THE NATURE OF THE INSTALLATION PROCEDURE.
lci1.com
for iPhone
®
for Android users.
™ ™
are registered trademarks
®
are trademarks
™
574-537-8900
Solera
Installation and Owner's Manual
(For Aftermarket Application)
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.

Prior To Installation

All screws supporting the awning assembly must have a
backer within the structure of the wall of the unit. Refer to
and
®
the unit manufacturer for proper location.
This manual will refer to the "drive side" and "idler side"
throughout for various instructions. The "drive side" is the
right hand side of the awning when facing the awning from
the exterior of the unit. The "idler side" is the left hand side
of the awning when facing the awning from the exterior of
the unit.

Resources Required

• 1-3 People, depending on the task
• Cordless or Electric Drill or Screw Gun
• Appropriate Drive Bits
• Rivet Gun (if needed)
• Non-Permanent Method of Marking
• Silicone Sealant or Butyl Tape
• Screwdriver
• Silicone Lubricant
• Scissors/Utility Knife
• Wire Cutters/Strippers
2
CCD-0001261
Power Awning
®
Rev: 03.16.18
