Summary of Contents for Vintec V20BVCBK
- Page 1 User Manual V20BVCBK vintec.com...
- Page 2 User Manual V20BVCBK...
- Page 3 Vintec manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Vintec manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual.
- Page 4 Somes models are available in dedicated countries only. VINTEC offers no guarantee for our Beverage Center if it is being used for any purpose other than that for which it was specifically designed. VINTEC cannot be held responsible for any error in this manual.
- Page 5 - have a surge protector fitted to the electrical outlet; - away from the microwave oven. Certain microwave ovens do not have wave interference shield. When placed within 1 meter vicinity of the Beverage Center, they may affect the operation of the Beverage Center. User Manual V20BVCBK...
- Page 6 Your Vintec Beverage Center is equipped with 4 adjustable feet to facilitate easy leveling. VINTEC recommends that you screw the back feet toward the base so they are in the shortest position and adjust the front feet to level the Beverage Center.
- Page 7 Important: If the unit is unplugged, power is lost, or turned off, wait 5 minutes before restarting the unit. The Beverage Center will not start if you attempt to restart before this time delay. User Manual V20BVCBK...
- Page 8 An individual’s perception of noise is directly linked to the environment in which the Beverage Center is located, as well the specific type of models. VINTEC Beverage Centers are in line with international standards for such appliances. VINTEC will always do its utmost to satisfy its customers but will not retake possession of the goods due to complaints based on normal operating noise occurrences.
-
Page 9: Temperature Settings
1 degree Celsius. The temperature setting can be adjusted from 2º to 10º To visualize the “set” temperature, press and hold the UP or DOWN buttons, the “set” temperature will temporarily “flash” in the LED display for 5 seconds. User Manual V20BVCBK... -
Page 10: Adjustable Shelves
When removing any of these shelves out of the rail compartment - to fit or remove the shelf - tilt the shelf as per the diagram and simply pull out, or push in the shelf until it sits on the support brackets securely. User Manual V20BVCBK... -
Page 11: Reversibility Of The Door
7. Insert the plastic caps to cover the holes(8). opening side. 7. Insert the plastic caps to cover the holes(8). V20BVCBK V20BVCBK AL-V40BVC 1 Lower hinge (Right) - Page 12 Height 810mm – 830mm (10mm adjustable feet) Width 295 – 300mm Depth 561– 592mm + 30mm stopper (Total of 622mm) 2. This Vintec Beverage Center is not designed to be fully integrated behind a joinery door. 1 Lock screws 2 Lower hinge (Right)
-
Page 13: Vent Specifications
VENT SPECIFICATIONS Front View (V40) Front View Front View (V20) Front View (V26) Cross section Front View (V20) 400mm User Manual V20BVCBK... - Page 14 5. This Vintec Beverage Center is front venting. The cabinet draws air from the front and rear and expels through the grill under the door at the front. If a joinery kick board is being placed in front of the Beverage Center, a grill of at least the same width as the Beverage Center grill and with a minimum airflow allowance of 150cm2 must be installed into the kick board.
- Page 15 Dimension and Installation Guide 40 Beer-Bottle Beverage Centre V20BVCBK Dimensional drawings: V40BVC S3/BK Fro nt V iew Top View Sid e V i ew Spacer AL-V40BVC FRONT VIEW SIDE VIEW Spacer NOTE: Illustrations not to scale. All dimensions in millimetres.
-
Page 16: Power Failures
Similarly, any intervention on the electrical circuit should be performed by a qualified electrician. Notes: Any intervention performed by a non authorized technicians by Vintec will lead to the warranty being considered as null and void. POWER FAILURES In the event of a power interruption, all previous temperature settings are automatically erased and it will revert to a preset temperature setting . - Page 17 The Beverage Center is not level. The door will not close properly. The Beverage Center is not level. The door was reversed and not properly installed. The gasket is faulty. ( magnet or rubber is spoiled) The shelves are out of position. User Manual V20BVCBK...
- Page 18 (c) ‘ASC’ means Electrolux’s authorised serviced centres; (viii) insect or vermin infestation; (d) ‘Vintec/Transtherm’ is the brand controlled by Electrolux Home Products (ix) failure to comply with any additional instructions supplied with Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 the Appliance;...
- Page 19 User Manual V20BVCBK...
- Page 20 Service and support In the rare event that your Vintec cabinet does not perform to your satisfaction, contact our dedicated support team: 1800 771 776 concierge@vintecclub.com Vintec. We are part of the Electrolux Family. To add a touch of professional inspiration to your home, visit electrolux.com.au...
