- Page 1 Armoire à vin Wine Preservation Technology USER MANUAL V26SG e SS/S3 models V30SGme/AL/S3/BK models V30SGe/AL/S3/BK models V40SGe/AL/S3/BK models V30SG2e/AL/S3/BK models V40SG2e/AL/S3/BK models V40DG 2e AL/S3/BK models code: VIM 201301/S/01...
- Page 2 Some models are available in dedicated countries only VINTEC offers no guarantee for our wine cellar if it is being used for any purpose other than that for which it was specifically designed. VINTEC cannot be held responsible for any error in this manual.
- Page 3 The room for installing the appliance must be at least 1 cubic metre per 8 grams of refrigerant. The refrigerant quantity contained in this appliance is listed above in grams; it is also noted on the Rating Plate of the appliance. It is hazardous for anyone other than an Authorised Service Person to carry out servicing or repairs to this appliance.
-
Page 4: Installing Your Wine Cellar
Leveling your wine cellar: The wine cellar must be leveled BEFORE loading your wines. Your Vintec wine cellar is equipped with 4 adjustable feet to facilitate easy leveling. VINTEC recommends that you tighten the back feet to the maximum and adjust the front feet to level the wine cellar. - Page 5 Fixing the Back spacer: Compressor run appliances require proper ventilation for proper and longer usage. Your Vintec wine cellar is supplied with a back spacer. Affix the back spacer at the back of the cellar for air circulation and heat evacuation.
- Page 6 3. Vintec “Built in” wine cellars draw air from the rear and expels through the metal grid under the door at the front. If a kick board is to be placed in front of the wine cellar’s grid another one must be fitted into the kick board with a minimum air flow allowance of 150cm2.
- Page 7 INSTALLATION DRAWINGS FOR BUILT IN WINE CELLARS: (UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CELLARS ONLY 30 mm This applies to all V40SG/DG BK&S3 models * only 10mm requires for V26 etc. code: VIM 201301/S/01...
- Page 8 Dimensional drawings: V26’s V40’s (30mm recess plinth) code: VIM 201301/S/01...
- Page 9 V40’s (85mm recess plinth) V40 S3/BK models TURNING ON YOUR WINE CELLAR Plug in and switch on the cellar by pressing on the power button for a few seconds. When you use the wine cellar for the first time (or restart the wine cellar after having it shut off for a long time), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout.
- Page 10 An individual’s perception of noise is directly linked to the environment in which the wine cellar is located, as well the specific type of models. VINTEC wine cellars are in line with international standards for such appliance. VINTEC will always do its utmost to satisfy its customers but will not retake possession of the goods due to complaints based on normal operating noise occurrences.
- Page 11 12ºC. They can also be set to provide ideal serving temperature for full enjoyment of the wine’s qualities. Unless stated by the wine maker on the bottle, VINTEC recommends 7ºC for your champagne, 12ºC for whites and 18ºC for reds. (Refer to “Wine Service Temperature”...
-
Page 12: Temperature Settings
TEMPERATURE SETTINGS Important: The LCD displays by default the actual internal air temperature. The temperature settings are pre-set at the factory as below. In the event of a power interruption, all previous temperature settings are automatically erased and it will revert to the preset temperature settings. - Page 13 1 degree Celsius. The temperature setting can be adjusted from 6ºC to 18ºC. V40SG e, V40DG 2e (for each compartment) AL/S3/BK models V26SG e SS/S3 models The “DISPLAY LED” displays the internal temperature. The set temperature automatically appears by pressing either the UP or DOWN button...
-
Page 14: Led Light
10℃ to 18℃ in lower compartment. LED LIGHT When equipped with an LED light, you may turn the LED light of your VINTEC wine cellar on and off by pressing the “LIGHT” button on the control panel. When on the LED light will automatically switch off after 10mins. -
Page 15: Wine Serving Temperature Chart
Room temperature not exceeding 20ºC IMPORTANT INFORMATION ABOUT TEMPERATURE Your VINTEC wine cellar has been designed to guarantee optimum conditions for storing and/or serving your wines. Fine wines require long and gentle developments and need specific conditions in which to reach their full potential. -
Page 16: Adjustable Wooden Shelves
DEFROSTING/CONDENSATION/ HYGROMETRY/ VENTILATION Your wine cellar is designed with an “Auto-cycle” defrost system. During “Off-cycle” the refrigerated surfaces of the wine cellar defrost automatically. Defrosted water from the wine cellar storage compartment drains automatically and part of it goes into a drainage container, which is located at the back of the wine cellar next to the compressor. -
Page 17: Reversibility Of The Door
REVERSIBILITY OF THE DOOR Warning: To avoid accidents during the process of changing the door, we recommend that you get assistance. The glass door is heavy and may cause injury if dropped. - Depending on the model and the type of handle your wine cabinet is equipped with, you may have to rotate the door through 180 degrees. - Page 18 1 Lock screws 2 Lower hinge (Right) 3 Door axis 4 Top hinge (Right) 5 Door 6 Cabinet body 7 Top hinge (Left) 8 Lower hinge (Left) - Unscrew the lock screws to remove the door axis at the bottom of the door (Fig 1) - While holding the door firmly, pull the door (5) outward;...
- Page 19 V30 models 1 Rubber cover 2 Screw 3 Hole cover 4 & 7 Screw 5 Top hinge module 6 Door 9 Cabinet’s leg-short 8 Lower hinge module-Left - Unscrew and remove the decorative cover. (Fig.1) - While holding the door firmly, loosen and remove the top hinge, lift up and remove the door (See Fig.2) - Unscrew the lower hinge (8) - Remove the long cabinet leg (9) on the left side, and shift it to the right side.
- Page 20 V30SGM e BK model 1. Screws 2. Door axis 3. Door limit device 4. Door 5. Hinge Screws 6. Lower hinge 7. Top hinge (Right) 8. Hole cover 9. Top hinge (Left) - Open the door to a 90 degree angle, take out the 2 screws (1) from door axis (2), remove the door (4), remove the door axis (2) (Fig.
- Page 21 V40 AL models (30mm recess plinth) 1 Lock screws 2 Lower hinge (Right) 3 Door axis 4 Top hinge (Right) 5 Door 6 Cabinet body 7 Top hinge (Left) 8 Lower hinge (Left) - Unscrew the lock screws (1) (Fig. 1) to remove the door axis located at the bottom. - While holding the door firmly, pull the door (5) outward and take it out;...
- Page 22 V40 AL models (85mm recess plinth) 1 Lower hinge (Right) 2 Lock screws 3 Top hinge (Right) 4 Lock Screws 5 Top hinge (Left) 6 Lower hinge (Left) 7 Door - While holding the door firmly, remove the three lock screws (2) from the lower right hinge module, and remove it.（Fig.1) - Remove the three lock screws (4) from the top right hinge and remove the hinge (3).
- Page 23 V40 S3/BK models 1. Lower hinge (Right) 2. Screws 3. Door axis 4. Door 5. Top hinge (Right) 6. Hinge Screws 7. Top hinge (Left) 8. Hole cover 9. Lower hinge (Left) 10. Door limit device 11. Screw - Open the door to a 90 degree angle, take out the 2 screws (2) from lower door axis (3), remove the door (4), remove the axis plate (3) from the door (Fig.
-
Page 24: Operation Anomalies
Check fuse, if any. Make sure that the door is closed properly. If your wine cellar appears to be malfunctioning, unplug it and contact your VINTEC’s after sales service. Any intervention on the cold circuit should be performed by a refrigeration technician who should carry out an inspection of the circuit sealing system. -
Page 25: Troubleshooting Guide
TROUBLESHOOTING GUIDE Common problems may easily be solved, saving you the cost of a possible service call. Please read carefully the instruction manual and revert to troubleshooting guide chart. PROBLEM POSSIBLE CAUSE Wine cellar does not operate Not plugged in. The appliance is turned off. - Page 26 R600a： Technical data SS/S3 AL-S3-BK AL-S3-BK AL-S3-BK AL-S3-BK AL-S3-BK V26SG e V30SG me & e V40SGe V30SG2e V40SG2e V40DG2e Models Capacity 750ml Bottles Upper 12 Upper 16 Left 19 Lower 19 Lower 28 Right 19 Gas charge quantity Net capacity 81.2L 124L 146L...
- Page 27 R134a： Technical data AL-S3-BK AL-S3-BK AL-S3-BK AL-S3-BK V40SG2e V40SGe(115V) V40DG2e(115V) V40SGe Models Capacity 750ml Bottles Upper 16 Left 19 Lower 28 Right 19 Gas charge quantity Net capacity 134L 146L 120L 146L upper 6 Left 7 Pre-set temp in degrees Lower 12 Right 12 Upper 6-12...
- Page 28 Copyright: All rights are reserved. All photocopying, reproduction, translation whether partial or total are strictly prohibited, without prior written consent from VINTEC. www.vintec.co.nz code: VIM 201301/S/01...
