User s Manual
NOTE: PLEASE INSPECT HOOD
IMMEDIATELY UPON RECEIVING.
CLAIM OF DAMAGE AFTER 7 DAYS
OF DELIVERY WILL BE DENIED.
This unit is designed for indoor
residential use only. DO NOT USE
OVER A WOOD GRILL OR MOUNT
IN OUTDOOR ENVIRONMENT.
Please read this operation manual thoroughly before
using your range hood. Store it in a safe location for
when you need to reference it in the future.
WS-3230SS
WS-3236SS
WS-3242SS
WS-3248SS
www.windsterhood.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Windster WS-3230SS
Summary of Contents for Windster WS-3230SS
- Page 1 User s Manual WS-3230SS WS-3236SS WS-3242SS WS-3248SS NOTE: PLEASE INSPECT HOOD IMMEDIATELY UPON RECEIVING. CLAIM OF DAMAGE AFTER 7 DAYS OF DELIVERY WILL BE DENIED. This unit is designed for indoor residential use only. DO NOT USE OVER A WOOD GRILL OR MOUNT IN OUTDOOR ENVIRONMENT.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Safety Information ............... 2 - 3 Content Checklist ..............4 Measurements ................5 Preparation ................6 - 7 Installation ................. 8 Operation & Features ............8 - 9 Cleaning & Maintenance ............10 Troubleshooting ..............11 Parts List / Replacement ............ -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION "CAUTION-To reduce risk of fire, properly exhaust air according to local city building code(s). "WARNING-To reduce the risk of fire or electric shock, do not use this fan with any solid- state speed control device.(Variable Speed Controller) "WARNING-TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY OBSERVE THE FOLLOWING: a) Installation work and electrical wiring must be done by qualified person(s) in... - Page 4 SAFETY INFORMATION D. Use an extinguisher ONLY if: 1. You know you have a Class ABC extinguisher, and you already know how to operate it. 2. The fire is small and contained in the area where it started. 3. The fire department is being called. 4.
-
Page 5: Content Checklist
CONTENT CHECKLIST CONTENT CHECKLIST CONTENTS INCLUDED a. (1) WS32 series(30" , 36" , 42" or 48")hood assembly b. (1) User’s manual c. (1) 7" conversion collar d. (2) Aluminum filters with frame & (2) stainless steel filler (30") e. (2) Aluminum filters with frame & (2) stainless steel filler (36") f. -
Page 6: Measurements
MEASUREMENTS 15/16" Fig.1a 30" (14-7/8") 36" (17-7/8") 12" (side to duct center) 42" (20-7/8") 2-1/4" 48" (23-7/8") 8-1/4" 9/16" 10-7/8" (back to duct edge) power cable 1" x 1-1/2"(30") 4-1/8" 1" x 2-1/2"(36"-48") (back to duct center) 3" 2-1/2" 8-3/8" 7-7/8"... -
Page 7: Preparation
PREPARATION PREPARATION BEFORE YOU START **DO NOT INSTALL IF DAMAGED** **RETURN OR EXCHANGE WILL BE DENIED IF INSTALLED** a. Be sure you have all the content of your purchase and required tools for this installation. b. Installation may take at least 1 to 2 hours from start to finish. c. -
Page 8: Preparation
PREPARATION Fig. 1c - Cabinet FRONT OF CABINET CABINET BOTTOM VIEW 7.5-8" 11 (30" CABINET) ROUND 14 (36" CABINET) EXHAUST 17 (42" CABINET) 20 (48" CABINET) ELECTRICAL OUTLET ½" BACK OF CABINET e. For cabinet with recessed-bottom, use (2) 3" x 12" or 15" wood strips on both sides to balance the recession. -
Page 9: Installation
INSTALLATION INSTALLATION UNDER CABINET INSTALLATION (Top round outlet) Make sure all preparation steps are completed. Feed the wires coming out of the hood through the bottom of the cabinet. Lift the unit up flesh against the wall and the bottom of the cabinet. Using the screws and washers provided, insert into each of the keyhole openings and tightly secure the unit against the bottom of the cabinet. - Page 10 REMOVING THE FILTERS Aluminum Filter Set Baffle Filter (Optional) Push the handles back/down into the hood Pull up on the filter latch, tilt towards you and and. remove the filter. Tilt the filters towards you. Push the frame back/down into the hood. Tilt the frame out.
-
Page 11: Cleaning& Maintenance
CLEANING& MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. Please thoroughly clean the unit weekly as stainless steel can rust under certain condition or by improper cleaning. -
Page 12: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. WS-32 Series Light Issue (One light 1. -
Page 13: Parts List / Replacement
PART LIST / REPLACEMENT PART LIST / REPLACEMENT Description Description Hood body assembly Filter frame Aluminum filter Right Motor Left Motor Stainless steel oil tray Stainless steel filler Electronic cover Right Fan Control switch mount Left Fan Main board Fan Cover Main board bracket Oil Tunnel Light set (GU10) -
Page 14: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is determined to be defective, Windster will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. During the "labor"... -
Page 15: Warranty / Contact Us
Damage resulting from natural disasters (earthquake, flood, storm, etc.) Aluminum Filters, Baffle Filters, Charcoal Filters, and Oil Cup Filters Light Bulbs CONTACT US Windster Hoods, Inc. Email: Support@windsterhood.com www.windsterhood.com © Windster Hoods, Inc. Information subject to change without notice.
