Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Safety Information .............. 2 Content Checklist ..............4 Measurements ................5 Preparation ................6 Installation ................7 Installation Diagram ..............9 Operation & Features ............. 10 Cleaning & Maintenance ............11 Troubleshooting ..............12 Part List / Replacement ............ -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION TO REDUCE THE RISK OF A FIRE, ELECTRICAL SHOCK, AND/OR INJURY OBSERVE THE FOLLOWING: Unit is intended for indoor residential use only. If you should have questions, contact the manufacturer at the address or telephone number listed in the warranty. - Page 4 SAFETY INFORMATION TO REDUCE THE RISK OF FIRE, OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE SPEED CONTROL DEVICE. Regardless of heat level, never leave any surface materials unattended while operating an open flame. Always turn hood ON when cooking at high heat or when flambéing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
-
Page 5: Content Checklist
CONTENT CHECKLIST CONTENT CHECKLIST CONTENTS INCLUDED (1) WS-28TB series(30 or 36 hood assembly (1) Lower duct cover (18- (1) Upper duct cover (18- (2) Magnetic baffle filters (1) Screw packet CONTENTS NOT INCLUDED WS-28TBEXTDC (Extension duct cover) WS-28TBCFMR (CFM reducer) Aluminum or metal piping TOOLS REQUIRED (NOT INCLUDED) Safety gloves... -
Page 6: Measurements
MEASUREMENTS Fig. 1a Fig. 1b... -
Page 7: Preparation
PREPARATION PREPARATION BEFORE YOU START **BE SURE YOUR UNIT WILL FIT YOUR CEILING HEIGHT** **DO NOT INSTALL IF DAMAGED** **RETURN OR EXCHANGE WILL BE DENIED IF INSTALLED** Be sure you have all the content of your purchase and required tools for this installation. -
Page 8: Installation
INSTALLATION INSTALLATION 1. WALL MOUNT INSTALLATION Make sure all preparation steps are completed. Determine your ceiling height to see if you need an extension. i. Hood unit height = ii. Duct cover height = 18- (lower) + 18- (upper) iii. Minimumheight (duct cover only) = 18-3/4 iv. - Page 9 INSTALLATION 3. COLD WEATHER INSTALLATION (OPTIONAL) Check with your local building codes to see if a CFM reducer is an acceptable alternative to make-up air. Remove the WS-28TB CFMR (CFM Reducer) and inspect for any sign of defect or damage. (ie. Cracks, broken flips) AFTER COMPLETING Step A G of WALL MOUNT INSTALLATION Place the CFM reducer onto the outlet of the unit and seal the connection...
-
Page 10: Installation Diagram
INSTALLATION DIAGRAM INSTALLATION DIAGRAM Fig. 2b Fig. 2a Fig. 2c Fig. 2d... -
Page 11: Operation & Features
OPERATION & FEATURES OPERATION & FEATURES EASY ACCESS CONTROL SWITCH (from left to right) Button 1 OFF Button 2 Low Speed Button 3 Medium Speed Button 4 High Speed Button 5 Light Button 6 Delay Shutoff BAFFLE FILTERS (2) 14-7/8 10-5/8 baffle filters (3) 14-7/8 10-5/8 baffle filters... -
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING& MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. -
Page 13: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. WS-28TB Series Light Issue (All not 1. -
Page 14: Part List / Replacement
PART LIST / REPLACEMENT PART LIST / REPLACEMENT Description Description Duct cover bracket Transformer Duct cover Capacitor Hood bracket Motor support bracket Hood body assembly LED lights Squirrel cage motor Control switch Baffle filters x 3 (30 x2) Control board... -
Page 15: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is Labor: determined to be defective, Windster will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. During the "labor"... - Page 16 WARRANTY / CONTACT US WHAT IS NOT COVERED BY MANUFACTURE WARRANTY Damages resulting from any of the following: Improper installation or maintenance Any repair, modification, alteration or adjustment not authorized by the manufacturer or an authorized service dealer Misuse and/or accidents Incorrect electric current, voltage or power supply Improper setting of any control (Pressing multiple selections at the same time)
