Initial Setup and Configuration for
Digi Transport® WR21 , WR41 and WR44

Common Digi TransPort Setup Procedures for all Meter Types

2.1
PRE-CONFIGURATION OF DIGI TRANSPORT
Required equipment for this configuration:
• Digi TransPort WR21, WR41 or WR44
Computer or laptop
•
Ethernet cable
•
SIM and data plan purchased from a carrier (Verizon, ATT, etc.)
•
CONNECTING TO THE CARRIER
–
Insert the SIM into SIM 1 slot on the front of the Digi TransPort and screw on both WWAN antennas.
–
Connect the Ethernet cable to port 0 of the Digi TransPort (some models only have one Ethernet port).
–
Connect the Ethernet cable to the laptop.
–
Power on the Digi TransPort.
– Open a browser on the laptop; i.e., Internet Explorer, Firefox, Chrome, etc.
–
In the URL window type 192 .168 .1 .1. The default configuration of the Digi TransPort has the DHCP turned on so
the laptop will be given an IP address automatically. The built in WebUI of the router should now be displayed (see
section 1.2 for common problems if you aren't able to connect).
–
When the login screen comes up, type in the username and password. The default username and password is
username and password (all lower case). After login you will go immediately to the Home screen.
– On the menus to the left, just below the Home option, you will see the Wizards option. Click on Wizards and then
choose the Carrier Switching Wizard. Follow the directions in the Wizard and pick whichever carrier you've chosen.
If you are using Verizon there is nothing else to do. It might take 10-15 minutes but the Digi TransPort will self
•
register and populate its APN.
If you are using AT&T (and some others) then an APN must be manually entered here: Configuration-
•
Network>Interfaces>Mobile. Click on the button to Use custom APN instead of built-in APN and enter the
APN (Check with your carrier as to what APN your particular SIM uses, some common ones for AT&T are
broadband, INTERNET and i2gold). It may take 10-15 minutes for the Digi TransPort to register.
