Requires: 4-channel radio w/ 4 micro servos,
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
E261XMPO19650902
Outrunner Motor KM0283010
w / Propeller Adaptor HW2340100,
20A Brushless ESC , 3 cells 11. 1V
2100 mAh Li- Po battery & charger.
Specifications
*Specifications are subject to change without notice.*
INSTRUCTION MANUAL
41 in / 1040 mm
264 sq in / 17 sq dm
26 oz / 740 g
30 in / 760 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
Advertisement
Related Manuals for TWM Sky Link EP
Summary of Contents for TWM Sky Link EP
- Page 1 INSTRUCTION MANUAL Requires: 4-channel radio w/ 4 micro servos, Outrunner Motor KM0283010 w / Propeller Adaptor HW2340100, 20A Brushless ESC , 3 cells 11. 1V 2100 mAh Li- Po battery & charger. Specifications 41 in / 1040 mm Wing Span 264 sq in / 17 sq dm Wing Area 26 oz / 740 g...
- Page 2 I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 -9 SAFETY PRECAUTIONS BEFORE YOU BEGIN Apply instant glue Apply epoxy glue. (C.A. glue, super glue.) Must be purchased separately! Apply thread locker Assemble left and right Ensure smooth non-binding sides the same way.
- Page 3 Parts List 1. MAIN WING 1 pc. SCREW PM2x12mm -- 2 pcs SPINNER Ø36mm -- 1 pc. 2. SCREW PB2x14mm -- 4 pcs COWLING -- 1 pc. SERVO MOUNTING PANEL -- 1 pair SCREW PWA2x8mm -- 4 pcs PUSHROD Ø1.4x56mm w/ Threads (For Aileron) -- 2 pcs STRAPER -- 2 pcs 9.
- Page 4 Please look for pin-hole marks at under side of control surfaces. Screw PB2x14mm Screw 7x8mm Please choose either 02L & 02R or 03L & 03R or 04L & 04R that suits your servo. TWM PL8210010 CLEVIS WRENCH Bottom View PA1.7X8mm Pushrod Fuel Tube 1.4x56mm Ø...
- Page 5 C=C' Completed Ø1mm pilot holes for World Models control horn are pre-drilled. Elevator Pushrod Please look for pin-hole marks at under side of control surfaces. crew PB2 x 8mm TWM PL8210010 CLEVIS WRENCH 90mm 11mm PB2x8mm Fuel Tube d2xD4x4mm Horn Pushrod 1.4x316mm...
-
Page 6: Rudder Pushrod
Ø1mm pilot holes for World Models control horn are pre-drilled. Please Rudder Pushrod look for pin-hole marks at side of control surfaces. crew PB2 x 8mm TWM PL8210010 CLEVIS WRENCH 35mm Pushrod 1.4x378mm Ø 44mm Fuel Tube d2xD4x4mm Clevis PB2x8mm... -
Page 7: Radio Equipment
Canopy Screw PWA2x8mm 1.5mm 1.5mm PWA2x8mm PWA2x8mm Radio Equipment Install and arrange the servos as shown in the diagram. Screw PM2x10mm Mounting Plate 20A Brushless PM2x10mm Washer Double Sided-Tape d2xD5mm Washer d2xD5mm M2 Nylon Insert Lock Nut M2 Nylon Insert Lock Nut Battery J1(Pushrod Ø1.8x130) B alsa... -
Page 8: Main Landing Gear
Main Landing Gear Screw PWA2.3x12mm Screw PA2x6mm Mounting Plate Set Screw PA2x6mm Plastic Collar 2.6mm Collar Plastic Collar Front 1.5mm 1.5mm 2.6mm Collar Wheel 40mm Ø PWA2.3x12mm LANDING WIRE STRAPS Bottom View Main Wing Front M2.5x20mm Nylon Bolt d2.6xD9mm Nylon Washer d2.6xD9mm 2.5mm Nylon Washer... - Page 9 Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A =A ' B =B ' C =C ' E261XMPO19650902...
- Page 10 Adjust the control throws as shown in the diagram. These throws are good for general Rudder 20mm flying. You can adjust according to your personal preference. 20mm Elevator 10mm 10mm Aileron The ideal C.G. position is 51mm (2 in.) behind C.G.
- Page 11 Product Registration Form (US Customers) We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to Air Borne Models, 2403, Research Drive, Livermore, CA 94550.U.S.A . 1.Name: 2.Address: 3.Phone #:...
- Page 12 Pl8210010 Large Clevis Small Clevis E261XMPO19650902...
- Page 13 E261XMPO19650902...
- Page 14 E261XMPO19650902...
- Page 15 E261XMPO19650902...
- Page 16 The World Models Manufacturing Co., LTD. www .thew orldm odels .com E261XMPO19650902...
