Technical Data

Model Number
AC Combiner Box, Metered
XAM1-120
Accessories (Order Separately)
Enphase Mobile Connect™
CELLMODEM-01
Consumption Monitoring CT
CT-200-SPLIT (order two)
Electrical Specifications
Maximum system size
Rating
Maximum system voltage
Rated output current
Rated input current, each DG input
Maximum fuse/circuit breaker rating
(output)
Solar branch circuit breakers
Production Metering CT
Mechanical Data
Dimensions (WxHxD)
Weight
Ambient temperature range
Cooling
Enclosure environmental rating
Wire size
Altitude
Internet Connection Options
Integrated Wi-Fi
Ethernet
Cellular
Compliance
Compliance, Combiner Box
Compliance, Envoy-S
32
AC combiner with Enphase Envoy-S Metered™ for integrated revenue
grade PV production metering (ANSI C12.20 +/- 0.5%) and optional
consumption monitoring (+/- 2.5%).
Plug and play industrial grade cellular modem with five-year data plan
for residential systems up to 12 kW. (Available in the US, Puerto Rico,
and the US Virgin Islands.)
Split core current transformers enable whole home consumption
metering (+/- 2.5%).
11.5 kW at 240 VAC
Continuous duty
240 VAC
48 A
16 A
60 A
Three 2-pole 20A/240 VAC DIN rail-mounted breakers
200A solid core pre-installed on solar busbar and wired to Envoy-S
38.0 x 38.7 x 20.3 cm (15.0" x 15.3" x 8.0")
5.1 kg (11.2 lbs)
-40ºC to +46ºC (-40º to 115ºF)
Vented, natural convection
Outdoor, NRTL-certified, NEMA type 3R, polycarbonate construction
12 to 6 AWG copper conductors for branch inputs.
12 to 4 AWG copper conductors for combined output.
Follow local code requirements for conductor sizing.
To 2000 meters (6,560 feet)
802.11b/g/n
802.3, CAT5E or CAT6 UTP ®cable (not included)
Optional, CELLMODEM-01 (not included)
UL 1741
UL 916
CAN/CSA C22.2 No. 61010-1
47 CFR, Part 15, Class B, ICES 003
IEC/EN 61010-1:2010,
EN50065-1, EN61000-4-5, EN61000-6-1, EN61000-6-2
Metering: ANSI C12.20 accuracy class 0.5
© 2016 Enphase Energy Inc.
AC Combiner Box Installation
141-00030 Rev 02
