- Page 1 M 2 3 2 - N 7 0 2 - 0 0 1 HIGH PERFORMANCE Super Night Vision Camera OPER ATION MANU AL Th a n k you f or c ho osin g our high qual i ty ca m e ra . Be fore a tte m pti ng to connect operate this unit,please read and follow these instructions.
- Page 2 C ON TE N T S NOTICES FOR YO UR SA F ET Y FEAT UR ES COMPO NE NT S OVER VI E W AND F UN C TI O N INSTAL LAT I O N CONNE CT I ON DIM E NSI O NS SP E CI F IC AT I ON S 1 0.
- Page 3 1 . NO TI CE S This device complies with Part 15 of FCC regulations. Operation is subject to the following two conditions; 1. This device may not cause harmful interference. 2. This device may receive interference that can cause affect the opration of this equipment.
- Page 4 1 . NO TI CE S Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature indicates that it should not be disposed with other household wastes at the end of its working life.
-
Page 5: For Your Safety
2 . F OR Y OU R SA F E T Y 1) All warnings and instructions in this manual should be followed. 2) Save this manual for future reference. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. - Page 6 3 . F EATU R E S • Superlative resolution of over 750 horizontal TV lines for amazing image quality. • 960H CCD for sensor sensitivity of .001 Lux in low light without DSS boost. 960H CCD sensor with high IR sensitivity. •...
- Page 7 4 . CO M P O NE N T S SUPER NIGHT VISION CAMERA VIDEO OUTPUT TEST CABLE L-WRENCH / SCREW - 4ea OPERATION MANUAL...
-
Page 8: O V Erv I E W An D F Un C T I O N
5 . O V ERV I E W AN D F UN C T I O N ① ② ① S u ns hie ld ② C abl e C onc eal ed T hr u B r ac ke t ③... - Page 9 5 . O V ERV I E W AN D F UN C T I O N • External Zoom & Focus Adjustable External Zoom & Focus Adjustable...
-
Page 10: Installation
6 . IN STAL L AT I O N • MOUNTING POSITION 360° PAN 90° TILT 90° TILT 360° PAN... -
Page 11: Monitor Connection
7 . CO NN E CT I ON • MONITOR CONNECTION (1) 12VDC 12VDC POWER SUPPLY VIDEO IN MONITOR (1) 24VAC/12VDC 24VAC POWER SUPPLY or 12VDC POWER SUPPLY VIDEO IN MONITOR BNC FEMALE When you install the camera, please glue up the end of cable to keep it stable in order to protect the camera from the humidity problems. - Page 12 8 . D IM E NS I O N S Unit : mm 98.6 30 LED SENSOR 110.6 243.3 M12XP1.25 (2EA) Ø95...
-
Page 13: Specification
9 . S PE CI F I C AT I O N Signal Format NTSC Image Device 1/3" 960H High Sensitivity CCD Scanning System 2 : 1 Interlace Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V) Total Pixels 1020(H) X 508(V) 1020(H) X 596(V) Effective Pixels 976(H) X 494(V) 976(H) X 582(V) - Page 14 1 0 . O SD M E N U S T R U C T UR E Main Menu 1st Sub Menu 2nd Sub Menu 3rd Sub Menu 4th Sub MENU BRIGHTNESS 0 - 255 IRIS SPEED 0 - 15 LENS RETURN SAVE&END...
- Page 15 1 0 . O SD M E N U S T R U C T UR E Main Menu 1st Sub Menu 2nd Sub Menu 3rd Sub Menu 4th Sub Menu D→N LEVEL 0 - 255 D→N DELAY 1, 3, 5, 10, 15, 20, 25, 30 AUTO N→D LEVEL 0 - 255...
- Page 16 1 0 . O SD M E N U S T R U C T UR E Main Menu 1st Sub Menu 2nd Sub Menu 3rd Sub Menu 4th Sub Menu OFF / ON AREA1 / AREA2 / AREA3 / AREA4 AREA SEL.
