- Page 1 energiSava® 200 WALL & FLOOR MOUNTED VERSION INSTALLATION GUIDE FOR ENGINEER / INSTALLER...
-
Page 2: Pre-Installation Checklist
Safety SAFETY AND RECOMMENDATIONS Be sure to have read and understood these instructions before beginning the installation • All wiring must comply with Building process. Regulations and the current I.E.E. Wiring Regulations (BS7671) or the equivalent PRE-INSTALLATION CHECK LIST standards for your country. The final Make sure that the unit can physically fit in to installation should be examined and tested the desired location. - Page 3 Wiring Commissioning - Electrical Connections All wiring must be completed by a qualified electrician. This appliance is suitable for 230V The appliance must be earthed and a double ~ 50Hz single phase supply fused at 3 amps. pole switch having a minimum contact separation of 3.0mm must be used to provide The appliance is supplied with a 4 core mains isolation for the unit.
-
Page 4: Technical Specifications
Technical Specifications Dimensions (mm) Maximum Flow Rate 67 l/s (241m /h) MAX Heat Exchanger Counter Flow (Plastic) EC (Electronically Fans Commutated DC) Electrical Supply 230V/1PH/50Hz Max Power 140W Consumption Protection Class IPX2 Supply Filter Extract Filter Spigot ø 125mm Dimensions 571 x 646 x 335mm 14kg Weight... - Page 5 Thank you for choosing EnviroVent The fastest growing ventilation company in the UK You are about to install a product that is designed to outlast the life-cycle of the building. Once installed the unit will operate continuously for 5 years and beyond without a major service. Please therefore ensure that this product is treated with care and installed properly i.e.
-
Page 6: Installation Instructions
Installation Instructions Control Options Frost Protection Intellitrac Humidity Tracking ® When the cell temperature in the unit falls When the energiSava® 200 unit senses a rise below 5°C the unit automatically warms the in humidity, caused by increased moisture cell with extracted air to prevent the formation generation such as through cooking or of frost. - Page 7 (on the wall). It can also be floor mounted in a loft space with an additional*drainage kit. EnviroVent Part number KITCONDENSATE-ES200. 5. Also make sure that there is a free space at the front of the appliance for cleaning the filter and carrying out maintenance on the appliance.
- Page 8 Installation Instructions SECOND FIX - Installing the unit 3. Slide the unit onto the wall bracket and attach ducting and drain. 1. Attach the wall bracket to a flat stable surface that is capable of bearing the unit’s weight, 14Kg. Ensure that bracket is positioned so that there is enough space for the condensate drain and ducts to be Pre-fixed bracket...
-
Page 9: Second Fix
Installation Instructions SECOND FIX Airflow and drain fitting - LH units Airflow and drain fitting - RH units Wall Wall mount mount Do not remove Do not remove the flexible plug the flexible plug Drains are factory fitted. The units have either a LH or RH drain. AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER... - Page 10 Floor mounting Connect 22mm PVC drain fitting 6. The unit can be floor mounted in a loft space with an additional kit. EnviroVent Part 5. The drainage from the unit may be number KITCONDENSATE-ES200. Use the connected to an internal waste water...
- Page 11 Installation Instructions SECOND FIX - Drainage for floor mounted units To atmosphere Extract from dwelling From atmosphere Supply to dwelling Place stopper provided into the fitted drain. AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
- Page 12 Commissioning Part 1 Commissioning of a continuous running ventilation system - MVHR • Commissioning of the system is necessary to Adjust using buttons, press provide adequate ventilation to the dwelling, as up or down until the total extract rate is stipulated in Approved Document F (ADF) of met.
- Page 13 Commissioning Part 2 Commissioning mode is chosen by pressing the SET button for 4 seconds, all sensor Setup guide for the energiSava ® inputs will be disabled in this mode so that they do not interfere with flow rates. All LEDs The control panel is found on the bottom of the unit.
- Page 14 Commissioning Part 2 Boost Control Versions Batteries When the battery requires changing, unclip the The energiSava® 200 operates continuously on switch front cover. The batteries are located on the ‘Normal’ setting to ensure the home is ventilated at back of the cover. Battery type - AAA x 2. the appropriate level although you can boost the system via the remote control switch.
- Page 15 Inform building owner/user on how to operate and ✓ maintain the system These checks are required to ensure the proper function of this unit. For EnviroVent Technical help call 01423 810 810 AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
-
Page 16: Maintenance
Filter maintenance is required for the proper function of the unit, not doing so may invalidate the warranty. Major service This is to be carried out at five years by EnviroVent or approved maintenance company. SHOULD YOU ENCOUNTER ANY PROBLEMS 0345 27 27 810 INSTALLING THIS UNIT, CALL US ON: energiSava®... - Page 17 Maintenance Disassembly of unit for engineering access and maintenance 1. Remove the entire front cover...held on with 3. Carefully remove the top foam moulding by x 2 screws at the bottom of the unit. Do pulling it straight forward. not adjust screws at the top of the unit, the Foam mouldings must remain parallel.
-
Page 18: Terms Of Warranty
Warranty Conditions & Exclusions The EnviroVent energiSava® 200 is covered by a full 5 year warranty which will benefit the occupier over many years. In the event that the product requires servicing, maintenance or reaches the end of its useful life, the quick, simple component replacement programme will ensure minimal disruption - no... - Page 19 AFTER INSTALLING THIS UNIT, DO NOT THROW AWAY PLEASE PASS ONTO END USER...
- Page 20 Your feedback is important to us as we strive to improve our and improvement EnviroVent reserves the products, services, and overall customer experience. Please email right to alter products specification and us to help us serve you better: feedback@envirovent.com appearance without notice.
