SUPER
WDR/3D DNR
IR BULLET CAMERA
USER'S MANUAL
Sony 1/3" Color Vertical Double Density CCD
Super WDR/3D DNR
Zero Defect
High Resolution of 600 TV Lines
Sens Up(x512, DSS)
DIS(Digital Image Stabilization)
Polygonal Privacy Masking
D.Zoom(x1~x10)
Eclipse
High Sensitivity Day&Night
7-2D002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL-2WTD66VAH and is the answer not in the manual?

Questions and answers

Related Manuals for Avico AL-2WTD66VAH

Summary of Contents for Avico AL-2WTD66VAH

  • Page 1 SUPER WDR/3D DNR IR BULLET CAMERA USER’S MANUAL Sony 1/3” Color Vertical Double Density CCD Super WDR/3D DNR Zero Defect High Resolution of 600 TV Lines Sens Up(x512, DSS) DIS(Digital Image Stabilization) Polygonal Privacy Masking D.Zoom(x1~x10) Eclipse High Sensitivity Day&Night 7-2D002...
  • Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 Precaution Do not Keep the camera face to strong light directly Do not install the camera in extreme temperature conditions. Do not disassemble the camera even if troubles happened To avoid malfunctions, never use the camera close to a gas or oil leak Do not drop the camera or subject them to physical shocks.
  • Page 4 1. Features SUPER WDR(Wide Dynamic Range) Wide Dynamic Range to the camera which provides superior images, internally and externally, even under extreme light and dark contracts. It automatically compensates the necessary light levels to get detailed information in the dark part of the image without saturation from the bright part.
  • Page 10 DC Power Connecting Adaptor Power (Adaptor Plug) Video Cable RS485 -(White) (Option) RS485 +(Orange) RS485 - RS485 + Monitor PORT2 PORT1 RX TX RX AC Power Connecting Power Adaptor Video Cable RS485 -(White) (Option) RS485 +(Orange) RS485 - RS485 + Monitor PORT2 PORT1...

  • Page 11: Setup Menu Flow

    5. Setup Menu Flow EXPOSURE LENS DC, ELC E.SHUTTER AUTO, 1/50(PAL),1/60(NTSC), 1/100,000 ON<1~256>, OFF SUPER WDR WDR LEVEL<0~10> OFF,LOW,MID,HIGH SENS-UP AUTO, OFF, MANUAL (x2 ~ x512) RETURN COLOR WB MODE AWC, ATW, MANUAL, PUSH R-Y GAIN B-Y GAIN RETURN DAY&NIGHT D&N MODE AUTO, DAY, NIGHT, EXT LEAD TIME...
  • Page 12 MOTION ALARM OFF, ON SET WINDOWS ALL SET ALL CLEAR SENSITIV SHOW OFF, ICON, TRACE DELAY TIME <1~15> RETURN PRIVACY MASK1 SETWINDOWS COLOR SET<1~8> MASK8 SET WINDOWS COLOR SET<1~8> RETURN SYNC SYNC MODE AUTO, INTER V-PHASE <0~199> RETURN COMMUNICATION ADDRESS <0~254>...

  • Page 13: Special Features

    6. Special Features 1. SUPER WDR(Wide Dynamic Range) Wide Dynamic Range is essential for capturing the images at all light levels. EXPOSURE LENS SUPER WDR E.SHUTTER 1/60 -------- WDR LEVEL SUPER WDR HIGH RETURN SENS-UP MANUAL RETURN - WDR Low level (0~3) : WDR mode in general or low light condition - WDR Middle Level (4~7) : WDR mode in middle light condition - WDR High Level (8~10) : WDR mode in strong light condition * Factroy default level : O (WDR On mode)
  • Page 14 2. 3D DNR(Digital Noise Reduction) Select 3D DNR ON or OFF. 3D-DNR function reduce the background noise in a low luminance environment. Upgraded 3D filtering ensures even more clear image. [DNR Level High : Picture image is more clear but Ghost is more increased. DNR Level Low : Picture image is not clear but less Ghost.] MAIN MENU FUNCTION...

  • Page 15: Specifications

    7. SPECIFICATIONS TV System NTSC Sensor Sony 1/3” Color Vertical Double Density CCD Synchronization Internal H/V 15.734/59.94Hz H/V 15.625/50Hz Line Lock H/V 15.750/60Hz H/V 15.625/50Hz Scanning System 2:1 Interlace Horizontal Resolution 600 TV Lines (Max.) / 700TV Lines(B/W) Min. Illumination 0.12Lux(15IRE), 0.2Lux(30IRE), 0.4Lux(50IRE) F1.2 Sens -Up On 0.0002Lux(15IRE), 0.0005Lux(30IRE), 0.0008Lux(50IRE) F1.2...

  • Page 16: Product Warranty Card

    PRODUCT WARRANTY CARD 1) ITEM # : 2) S/N # : 3) INSTALLATION CONDITION - Indoor / Outdoor - Power supply SPECIFICATION : DC12V / AC24V CURRENT __________ mA 4) TROUBLESHOOTING - No picture - Bad image - No power - Water damage - LED ON / OFF...
