Avico APO-SDI20M-NX20W Instruction Manual

Hd sdi megapixel ptz dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Ver 1.3
HD SDI Megapixel PTZ Dome Camera
HC0213FEB18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APO-SDI20M-NX20W and is the answer not in the manual?

Questions and answers

Related Manuals for Avico APO-SDI20M-NX20W

Summary of Contents for Avico APO-SDI20M-NX20W

  • Page 1 INSTRUCTION MANUAL Ver 1.3 HD SDI Megapixel PTZ Dome Camera HC0213FEB18...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 3 NOTICE Important Safety Guide 1. Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. 2. Keep this manual Keep this manual for reference in future. 3. Attachments / Accessories Use only the attachments or accessories specified by the manufacturer. 4.
  • Page 4 NOTICE Caution  Operating  Before using, make sure that the power supply and others are properly installed.  While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. ...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS ① Introduction Model Code Features Package Components Main Part Description ② Installation DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Wiring and Cabling ③ Operation Check Point before Operation Check Points for Preset and Pattern Function before Operation OSD Menu Reserved Preset (Hot Keys) Preset...

  • Page 6: Model Code

    INTRODUCTION Model Code APO-SDI20M-NX20W Mount Bracket W : Wall Mount C : Ceiling Mount NTSC Zoom X20 Optical 2M Pixels HD SDI APO : Avico, Ptz, Outdoor HD SDI Megapixel PTZ Dome Camera Instruction Manual 6/72...

  • Page 7: Features

    INTRODUCTION Features  Powerful Zoom Camera & Setup Options  Image Sensor 1/2.8" Exmor CMOS Image Sensor, 3 Mega pixels (30S model) 1/2.8" Exmor CMOS Image Sensor, 3 Mega pixels (20S model) 1/4" PS CMOS Image Sensor, 1.3 Mega pixels (30T model) 1/3"...
  • Page 8 INTRODUCTION  Powerful Pan/Tilt Functions  MAX. 500/sec High Speed Pan/Tilt Motion  With the Vector Drive Technology, Pan/Tilt motions are accomplished along the shortest path. As a result, the time to target view is remarkably short and the video on the monitor is very natural in monitoring.
  • Page 9 INTRODUCTION  MAX. 8 sets of Schedule are programmable. This function is that a camera runs a function such as Preset, Pattern, Swing or Group at an assigned time. Also this function can be run periodically by pre- defined schedules. ...

  • Page 10: Package Components

    INTRODUCTION Package Component  Product & Accessories  Main Body & Dome Cover (Wall/Ceiling model)  Main Body & Dome Cover (In-ceiling model)  Default Accessories [Main Cable, I/O Cable ,Wrench, Owners Manual] HD SDI Megapixel PTZ Dome Camera Instruction Manual 10/72...
  • Page 11 INTRODUCTION  Brackets (Optional)  Wall Mount Bracket  Ceiling Mount Bracket [Screws : , Hex Lag #1450] [Screws : , Anchor Bolt 3/8"70] TORX Machine M4L18 TORX Machine M4L18  In-Ceiling Mount Bracket [Screws : Tapping FH Ø 4L20, Machine Sams M3L8] HD SDI Megapixel PTZ Dome Camera Instruction Manual 11/72...

  • Page 12: Main Part Description

    INTRODUCTION Main Part Description Mounting Screw Hole Drop Prevention Spring DIP Switch Main Connector BNC Connector for SDI Sensor I/O Port Dome Cover  Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust.

  • Page 13: Dip Switch Setup

    INSTALLATION DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol.  Camera ID Setup  ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10...
  • Page 14 INSTALLATION  Communication Protocol Setup  Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Others Reserved  Match the camera protocol with the camera protocol in the setting of your DVR or controller to control the camera.

  • Page 15: Installation With Ceiling Mount Bracket

    INSTALLATION Installation with Ceiling Mount Bracket ① Remove the ceiling tile from the ceiling and ② Hook up Drop Prevention Spring on main cut a hole whose diameter is 30~40mm on the body to prevent camera from unexpected ceiling tile to pass the wire(s) and cable(s) drop and pull the wire(s) and cable(s) for the through to the upside of the ceiling.

  • Page 16: Installation With Wall Mount Bracket

    INSTALLATION Installation with Wall Mount Bracket ① Make a hole whose diameter is 30~40mm on ② Hook up Drop Prevention Spring on main the mounting surface to pass the wire(s) and body to prevent camera from unexpected cable(s) through the mounting surface. (In drop and pull the wire(s) and cable(s) for the case of the wiring and cabling through the system as below.
  • Page 17 INSTALLATION Installation with In-ceiling Bracket ① Assemble the dome cover and the braket ② Cut a hole whose diameter is 215mm on the with the main body ceiling tile and insert the camera into the hole. Open the cover and make all the connections. ③...

  • Page 18: Wiring And Cabling

    INSTALLATION Wiring and Cabling MONITOR for HD-SDI BNC CABLE (HD-SDI) POWER BNC(Composite) MAIN CABLE MONITOR RS-485 CONTROLLER / DVR SENSOR I/O DOOR SENSOR SWITCH I/O CABLE  Port Description  Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal Composite Video + BNC Connector...
  • Page 19 INSTALLATION  Power Description  Carefully check the voltage and current capacity of the rated power. Power Input Input Voltage Range Current Consumption DC12V Input DC 11V ~ 18V 1.8 A AC24V Input AC 17V ~ 29V 2.0 A  For the DC input, be careful with the polarity of DC power. The system should be permanentally damaged by wrong DC input.
  • Page 20 INSTALLATION  HD-SDI Video Output  Transmission Distance of HD-SDI Video Signal should be variable by cables. There may be no video on a monitor due to cable quality or specification. Use proper BNC Coaxial Cables after considering transmission distance. ...
  • Page 21 INSTALLATION  Alarm Input Before connecting sensors, check driving voltages and output signal types of the sensors. Since output signal types of the sensors are divided into Open Collector type and Voltage Output type in general, the wiring must be done properly after considering those types. Signal Description IN COM+...

  • Page 22: Check Point Before Operation

    OPERATION Check Points before Operation  Before turning on the system, check if the wire(s) and cable(s) are connected properly.  Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera.

  • Page 23: Osd Menu

    OPERATION OSD Menu  Function With OSD menu, the system can be properly configured for each application.  Entering into OSD Go Preset [95] Reserved Presets (Hot Keys)  Description Some Preset numbers are reserved to change some parameters without entering into OSD menu. ...

  • Page 24: Preset

    OPERATION Preset  Function MAX. 209 presets can be configured except the Reserved Presets (Hot Keys). Camera parameters such as White Balance, Auto Exposure and others can be set up independently and each preset can have its own parameter values independently from the other persets.

  • Page 25: Pattern

    OPERATION Pattern  Function This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. 4 Patterns are programmable and Maximum 768 communication commands can be programmed in a pattern.

  • Page 26: Group

    OPERATION Group  Function This function is that the camera memorizes the combination of Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 40 actions which are the combination of Preset, Pattern and Swing. Preset speed can be set up and the repeat number of Pattern &...
  • Page 27 OPERATION  Alarm Input 3 Alarm Inputs are available. When external sensors activate, the camera runs pre-defined actions such as Preset, Pattern, Swing and Group. After the pre-defined time period passed, Post Alarm activates, which is pre-defined. Note that only the latest alarm input is effective when multiple sensors are activated at the same time.

  • Page 28: Osd Display

    OPERATION OSD Display LABEL12345 PRESET 001 Preset Label Acrtion Title Alarm Information Time (Hour:Min:Sec) PTZ Information Camera ID Date (Day/Mon/Year) I:-2- O:1 CAM1 AM 00:00:00 01/JAN/2012 000/000/x001  P/T/Z Information Displays the pan/tilt positions and zoom magnification.  Camera ID Displays the selected Camera ID (Address).

  • Page 29: ④ Osd Menu

    OSD MENU Quick Programming Guide  To move the cursor in the menu, use the joystick to Up/Down direction Left/Right direction.  To change a value of an item, use Tele/Wide of the joystick in the controller.  The menu items >>...
  • Page 30 OSD MENU With Manual mode at presets, Focus data is memorized in each preset in advance and the camera calls focus data in correspondence with presets as soon as camera arrives at presets. It should shorten time to get focuses. Focus mode automatically changes to Auto Focus mode when jog operation starts.
  • Page 31  Auto DSS [ON/OFF] When set to ON, ensure that the slow shutter is set to automatically when the brightness drops. Effective only when the AE mode is set to AUTO. The Auto DSS function is not abailiable in WDR mode. ...
  • Page 32 OSD MENU Video Setup (30T, 20T, 19T model) VIDEO FOCUS MODE SEMIAUTO WHITE BALANCE AUTO ACTION - RED OFFSET - BLUE OFFSET SYSTEM SHUTTER MODE INFORMATION - SHUTTER 1/60 IRIS MODE AUTO - IRIS F1.6 GAIN MODE MEDIUM - GAIN 0 dB BRIGHTNESS BACKLIGHT...
  • Page 33 OSD MENU  Focus Mode [AUTO/MANUAL/SEMIAUTO] Sets camera Focus mode.  SEMIAUTO Mode This mode automatically exchanges focus modes between Manual Focus mode and Auto Focus mode by operation. Manual Focus mode activates in preset operation and Auto Focus mode activates during jog operation ...
  • Page 34 OSD MENU The WDR(Wide Dynamic Range) is a function for dividing an image into several blocks and correcting blocked-up shadows and blown-out hightlights in accordance with the intensity diffrence. It enables you to obtain images in which portions ranging from dark to light can be recognized, even when capturing a subject with a large intensity difference that is backlit or includes extremely light portions.
  • Page 35 OSD MENU  HD-SDI NTSC : [1080p30/1080i60/720p60/720p30] Resolution : [1080p25/1080i50/720p60/720p30] Sets the video resolution of HD-SDI. Match the resolution with the setting of monitor or DVR. If there is no confirmation within 10 seconds by pressing the NEAR button, it is automatically restored to its previous configuration.
  • Page 36 OSD MENU Video Setup (20W model) VIDEO FOCUS MODE SEMIAUTO WHITE BALANCE AUTO ACTION - RED OFFSET - BLUE OFFSET SYSTEM EXPOSURE MODE AUTO INFORMATION - SHUTTER 1/60 - IRIS - GAIN +19 dB - BRIGHTNESS DEFOG - LEVEL AUTO DSS APERTURE DAY&NIGHT AUTO...
  • Page 37 OSD MENU  Focus Mode [AUTO/MANUAL/SEMIAUTO] Sets camera Focus mode.  SEMIAUTO Mode This mode automatically exchanges focus modes between Manual Focus mode and Auto Focus mode by operation. Manual Focus mode activates in preset operation and Auto Focus mode activates during jog operation. With Manual mode at presets, Focus data is memorized in each preset in advance and the camera calls focus data in correspondence with presets as soon as camera arrives at presets.
  • Page 38 OSD MENU  WDR [OFF/ON] The WDR(Wide Dynamic Range) is a function for dividing an image into several blocks and correcting blocked-up shadows and blown-out hightlights in accordance with the intensity diffrence. It enables you to obtain images in which portions ranging from dark to light can be recognized, even when capturing a subject with a large intensity difference that is backlit or includes extremely light portions.
  • Page 39 OSD MENU Video Setup (28L, 30L model) VIDEO FOCUS MODE SEMIAUTO - FOCUS DIST 50cm ACTION WHITE BALANCE AUTO - MANUAL MODE INDOOR SYSTEM - RED OFFSET INFORMATION - BLUE OFFSET IRIS AUTO - LEVEL BRIGHTNESS SHUTTER MODE AUTO SENS-UP 3DNR MEDIUM WDR/BLC...
  • Page 40 OSD MENU  Focus Mode [AUTO/MANUAL/SEMIAUTO] Sets camera Focus mode.  SEMIAUTO Mode This mode automatically exchanges focus modes between Manual Focus mode and Auto Focus mode by operation. Manual Focus mode activates in preset operation and Auto Focus mode activates during jog operation ...
  • Page 41 OSD MENU  WDR/BLC [OFF/WDR/BLC] Sets Backlight Compensation. If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. The camera uses the center of the picture to adjust the iris. If there is a bright light source outside of this area, it will wash out to white.

  • Page 42: Privacy Mask Setup

    OSD MENU Privacy Mask Setup PRIVACY MASK MASK NO 1 UNDEFINED CLEAR MASK > DISPLAY MASK EDIT MASK >> MASK COLOR BLACK Privacy Zone Mask allows the user to program 8 rectangulars that can not be viewed by the operator of the system.
  • Page 43 EDIT MASK MOVE TO TARGET POSITION [NEAR : NEXT / FAR : CANCEL] Move your camera to an area to mask, and press NEAR button. Then a mask will be displayed in the center of screen.  Privacy Mask Size Setup EDIT MASK [LEFT&RIGHT:WIDTH/UP&DOWN:HEIGHT] [NEAR : NEXT / FAR : CANCEL]...

  • Page 44: Ptz Setup

    OSD MENU PTZ Setup VIDEO POWER UP ACTION ACTION AUTO PARKING - ACTION TYPE HOME SYSTEM - ACTION NUMBER INFORMATION - WAIT TIME 00:10:00 AUTO FLIP JOG MAX SPEED 120/SEC JOG DIRECTION INVERSE ZOOM PROPORTIONAL JOG FREEZE IN PRESET  Power Up Action [ON/OFF] Refer to Other Functions"...
  • Page 45 OSD MENU  Jog Direction [INVERSE/NORMAL] Sets the Jog Direction. If this is set to Inverse, the view direction in the screen is same as the direction of joystick. If this is set to Normal, the view direction in the screen is the reverse dirction of joystick.

  • Page 46: Action Setup

    OSD MENU ACTION Setup VIDEO ACTION MOTION EDIT LOCK PRESET >> SYSTEM SWING >> INFORMATION PATTERN >> GROUP >> ALARM TRIGGER >> SCHEDULE >>  Motion Edit [ON/OFF] Lock If Motion Lock is set to ON, it is impossible to set up and delete Preset, Swing, Pattern and Group.

  • Page 47: Preset Setup

    OSD MENU PRESET Setup PRESET PRESET NO 1 UNDEFINED CLEAR PRESET > EDIT SCENE >> EDIT LABEL >> [ RELAY OUT CAMERA LOCAL SETTING WHITE BALANCE AUTO - RED OFFSET - BLUE OFFSET EXPOSURE MODE AUTO - SHUTTER 1/60 - IRIS F6.8 - GAIN 2 dB...
  • Page 48 OSD MENU  Preset Scene Setup ① Use the Joystick to move the camera to a desired position. EDIT PRESET ② Save the preset position by pressing NEAR key. ③ Press FAR key to cancel targeting the preset position. MOVE TO TARGET POSITION [NEAR : NEXT / FAR : CANCEL] ...

  • Page 49: Swing Setup

    OSD MENU SWING Setup SWING SWING NO 1 UNDEFINED - 1ST PRESET 1 UNDEFINED - 2ND PRESET 1 UNDEFINED - SWING SPEED 30/sec CLEAR SWING > RUN SWING >  Swing Number [1~10] Selects a Swing number to edit. If the selected Swing is not defined, "UNDEFINED" is displayed.

  • Page 50: Pattern Setup

    OSD MENU PATTERN Setup PATTERN PATTERN NO 1 UNDEFINED CLEAR PATTERN > RUN PATTERN > EDIT PATTERN >>  Pattern No [1~4] Selects a Pattern number to edit. If the selected pattern number is not defined, "UNDEFINED" will be displayed. ...
  • Page 51 OSD MENU  Edit Pattern ① With the Joystick of your controller, move the camera to the start position with an EDIT PATTERN appropriate zoom magnafication. To start the pattern recording, press NEAR key. To exit, press FAR key. MOVE TO TARGET POSITION [NEAR : NEXT / FAR : CANCEL] ②...

  • Page 52: Group Setup

    OSD MENU GROUP Setup GROUP GROUP NO 1 UNDEFINED CLEAR GROUP > RUN GROUP > ------------------------------------------ NO ACTION TYPE ACTION NO DWELL OPTION ------------------------------------------ UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED 00:05 UNDEFINED...

  • Page 53: Alarm Trigger Setup

    OSD MENU ALARM TRIGGER Setup ALARM TRIGGER ALARM NO ALARM TYPE NORMAL OPEN TRIGGERED ACTION UNDEFINED TRIGGERED ACTION NO TRIGGERED HOLD TIME ENDLESS POST ACTION HOME POST ACTION NO  Alarm No [1~3] Selects a sensor number to set up. ...

  • Page 54: Schedule Setup

    OSD MENU SCHEDULE Setup SCHEDULE SCHEDULE NO SCHEDULED ACTION UNDEFINED SCHEDULED ACTION NO SCHEDULED HOLD TIME ENDLESS POST ACTION HOME POST ACTION NO ACTION CYCLE ONCE - YEAR 2012 - MONTH - DAY - HOUR - MINUTE - SECOND  Schedule No [1~8] Selects a Schedule to be configured.

  • Page 55: Osd Setup

    OSD MENU OSD Setup VIDEO ACTION DISP CAMERA ID SYSTEM DISP ALARM I/O AUTO INFORMATION DISP PTZ INFO AUTO DISP ACTION TITLE AUTO DISP PRESET LABEL AUTO DISP TIME DISP DATE OSD setup allows you to program how labels are displayed on the monitor. In case of AUTO, the labels are displayed on the monitor when there are any changes in parameters.
  • Page 56  [ON/OFF] Display Date Configures whether Date will be displayed in OSD or not  [ON/OFF] Display Time Configures whether Time will be displayed in OSD or not HD SDI Megapixel PTZ Dome Camera Instruction Manual 56/72...

  • Page 57: System Setup

    OSD MENU SYSTEM Setup VIDEO ACTION SYSTEM LANGUAGE ENGLISH INFORMATION TIME SETTING >> HEATER SETTING AUTO ENABLE PASSWORD EDIT PASSWORD >> FACTORY RESET > - RESET VIDEO > - RESET PTZ > - RESET ACTION > - RESET OSD > REBOOT SYSTEM >...
  • Page 58 OSD MENU  Factory Default  Video Menu Setting (30S, 20S Model) Focus Mode SEMIAUTO Day&Night AUTO White Balance AUTO Digital Zoom Exposure Mode AUTO Image Flip Stabilization Privacy Mask UNDEFINED Auto DSS HD-SDI Resolution 1080p30 (NTSC) Aperture 1080p25 (PAL) ...
  • Page 59 OSD MENU  Video Menu Setting (28L, 30L Model) Focus Mode SEMIAUTO Color White Balance AUTO Color Level Iris AUTO Day&Night AUTO Brightness Digital Zoom Shutter mode AUTO Image Flip Sens-Up Privacy Mask UNDEFINED 3DNR MEDIUM HD-SDI Resolution 1080p30 (NTSC) WDR/BLC 1080p25 (PAL) Sharpness...

  • Page 60: Time Setup

    OSD MENU TIME Setup TIME SETTING YEAR 2012 MONTH HOUR MINUTE SECOND . HOUR does not support AM or PM form. HOUR can be configured in 24 Configure current date and time hour form. HD SDI Megapixel PTZ Dome Camera Instruction Manual 60/72...

  • Page 61: Password Setup

    OSD MENU PASSWORD Setup As soon as finishing selecting ① an alphabet or a number, the cursor moves to the next CHANGE PASSWORD digit. With Left/Right/Up/Down of ② ---------- the joystick, move to a desired 1234567890 ABCDEFGHIJ character in the alphanumeric KLMNOPQRST set.

  • Page 62: ⑤ Specifications

    SPECIFICATIONS Specifications CAMERA PART (30S Model) Image Sensor 1/2.8'' Exmor CMOS Sensor Pixels 3,270K pixels 30 Optical Zoom, 12 Digital Zoom Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~4.7, f=4.61~138.3mm Angle of View (H) 57.5(Wide)~2.1(Tele) Min. Working Distance 10mm(Wide), 1200mm(Tele) Zoom Speed 4.6 sec (Wide to Tele) 0.5 Lux (Color, 1/30sec, 50 IRE)
  • Page 63 SPECIFICATIONS CAMERA PART (20S Model) Image Sensor 1/2.8'' Exmor CMOS Sensor Pixels 3,270K pixels 20 Optical Zoom, 12 Digital Zoom Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~3.9, f=3.5~129.5mm Angle of View (H) 55.4(Wide)~2.9(Tele) Min. Working Distance 10mm(Wide), 1000mm(Tele) Zoom Speed 2.3 sec (Wide to Tele) 0.5 Lux (Color, 1/30sec, 50 IRE) Minimum Illuminance...
  • Page 64 SPECIFICATIONS CAMERA PART (30T Model) Image Sensor 1/4'' PS CMOS Sensor Pixels 1,300K pixels 30 Optical Zoom, 12 Digital Zoom Zoom Video Signal-to-Noise 50 dB Forcal Length F1.35~3.7, f=3.5~101.5mm Angle of View (H) H : 54.8(Wide)~2.01(Tele) / V : 44.6(Wide)~1.61(Tele) Min.
  • Page 65 SPECIFICATIONS CAMERA PART (20T Model) Image Sensor 1/3'' PS CMOS Sensor Pixels 2,000K pixels 20 Optical Zoom, 8 Digital Zoom Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~2.9, f=4.45~89mm Angle of View (H) H : 55.56(Wide)~3.10(Tele) / V : 43.32(Wide)~2.34(Tele) Min.
  • Page 66 SPECIFICATIONS CAMERA PART (19T Model) Image Sensor 1/3'' PS CMOS Sensor Pixels 1,300K pixels 19 Optical Zoom, 16 Digital Zoom Zoom Video Signal-to-Noise 52 dB Forcal Length F1.6~2.9, f=4.5~85.5mm Angle of View (H) H : 55.24(Wide)~3.16(Tele) / V : 44.96(Wide)~2.542(Tele) Min.
  • Page 67 SPECIFICATIONS CAMERA PART (20W Model) Image Sensor 1/3'' Panasonic CMOS Sensor Pixels 2,000K pixels 20 Optical Zoom, 12 Digital Zoom Zoom Video Signal-to-Noise 50 dB Forcal Length F1.6~3.5, f=4.7~94.0mm Angle of View (H) 55.4(Wide)~2.9(Tele) 0.5 Lux (Color) Minimum Illuminance 0. 001 Lux (B/W, DSS) Day &...
  • Page 68 SPECIFICATIONS CAMERA PART (30L Model) Image Sensor 1/2.8'' CMOS Sensor Pixels 3,270K pixels 30 Optical Zoom, 12 Digital Zoom Zoom Forcal Length F1.6~5.0, f=4.3~129.0mm Minimum Illuminance 0.8 Lux (Color, Sens-up Off ) / 0. 1 Lux (B/W, Sens-up Off ) Day &...
  • Page 69 SPECIFICATIONS CAMERA PART (30L Model) Image Sensor 1/4'' CMOS Sensor Pixels 1.3M pixels 28 Optical Zoom, 12 Digital Zoom Zoom Forcal Length F1.5~3.7, f=3.5~98.0mm Minimum Illuminance 0.8 Lux (Color, Sens-up Off ) / 0. 01 Lux (B/W, Sens-up Off ) Day &...
  • Page 70 SPECIFICATIONS MECHANISM PART 360(Endless) Movement Range Tilt 90 Preset 500/sec. Speed 0.05 ~ 360/sec. (Proportional to Zoom) Swing 10~ 180/sec. Preset 209 Presets (Label, Independent Camera Parameter Setting) Pattern 4 Patterns [768 Commands(Approx. 5 Minute) / Pattern] Swing 10 Swings 8 Groups (MAX.
  • Page 71 SPECIFICATIONS MECHANICAL Ceiling Mount Wall Mount In-Ceiling Mount Dome Polycarbonate Material Internal Polycarbonate, ABS External Aluminium Polycarbonate 150mm /  5.9 Dome Size 200407.8 mm 253259 mm Dimension 300309.1 mm Weight Approx 3.6 Kg Approx 3.4 Kg Approx 2.3 Kg [Note] 1) Specification and features are subject to change without prior notice.

  • Page 72: Dimension

    SPECIFICATIONS Dimension  Main Body  Ceiling Mount Type 56.4 56.4 1.5" NPT 158.2  Wall Mount Type  In-Ceiling Mount Type 118.6 4- 8 [Unit : mm] HD SDI Megapixel PTZ Dome Camera Instruction Manual 72/72...
