Mode
Automatic mode -
rotating
Automatic mode -
scanning
Laydown mode -
rotating
Laydown mode -
scanning
Manual mode -
rotating
Manual mode -
scanning

Automatic / Manual modes

The Agatec RL110 is in automatic, self-leveling mode when turned on.
Once the instrument has self-leveled, the laser head will start rotating with
600 rpm.
In manual mode, the laser does not self-level; this means that the
beam will rotate even if the laser is not leveled. It can therefore be
used on inclined planes such as stairs, roofs, or when manual grade
setting is required. See later section on setting slope in manual or
semi-automatic modes.
H.I. Alert mode
The H.I. feature stops the laser automatically if the laser is disturbed,
preventing inaccurate readings. It functions only when activated.
•
To activate this safeguard feature, keep pressed the H.I. key {B-2} after
turning on the laser. The H.I. LED {B-8} will blink rapidly while the laser
is initializing the H.I. mode.
RIGHT / LEFT
Moves CW/CCW
mode
Moves scan
CW/CCW
Slope
Slope
Slope
Slope
UP / DOWN
Cycle through the
rotating speed
Cycle through the
scanning width
Cycle through the
rotating speed
Cycle through the
scanning width
Cycle through the
rotating speed
Cycle through the
scanning width
