Thirty seconds later, the LED will blink slowly, indicating the H.I. Alert
function is activated.
•
If the laser is disturbed while in H.I. Alert mode, the head will stop
rotating, the beam will turn off, all LEDs will blink red.
•
Press the ON/Off key to turn off the H.I. Alert function. Press again the
ON/OFF key to have the unit going back to the default settings (600 rpm,
automatic mode).

Rotation mode

The head rotates at three speeds: 0, 300, 450, 600 rpm. The default setting
is 600 rpm. The laser beam is more visible at slower rotation speeds.
• To cycle through the rotation speeds press the
to get to point mode, twice to 300 rpm, three times to get to 450 rpm.
One more time to get back to 600 rpm.
• When in point mode, the point can be moved to the right or left using
the UP/DOWN keys {B-3 and B-4}. It is also possible to move the head
manually to position the beam point.
To start rotation again, press the

Scanning mode

For interior applications, scanning mode allows you to see the beam
easier at a distance.
The default width has medium dimension. The laser beam is more visible
at small width.
• To scan press the
• To cycle through the scan width, press the
• The scanning beam can be moved to the right or left using the
UP/DOWN keys {B-3 and B-4}.

Wall Mount

For interior application, such as drywall installation, it is recommended to
use the wall mount.
Use the tripod thread to fix the mount to the laser.
8
key {B-5}.
key {B-6}.
key {B-5}. Press once
key {B-6}.
