Basic Operation

How to use your Agatec RL110

Horizontal Setup
The laser can be mounted on a 5/8"-11 tripod or placed directly on a
solid, stable surface. Agatec RL110 can be suspended from a ceiling
grid using the wall mount.
Vertical Setup
The laser can be placed directly on its back (opposite the handle) on a
solid, stable surface. For more stability, it is recommended to use the wall
mount.
Turning on the laser
Turn on the laser with the On/Off key {B-1}. It does a self-test and the
beam blinks while the laser is self- leveling. After it is leveled, the head
rotates. You can choose H.I. Alert mode or change to manual mode (see
later sections).
The laser has a wide self-leveling range; however, if the laser is set up out
of the leveling range, the laser beam will continue to blink and the
rotation will not start.
LED indication
The LED indicator {B-9} slowly blinks green and red while the axes
are leveling and stays on when both axis has reached a level position.

Button Functions

The UP/DOWN buttons on the laser and the remote control buttons have
multiple functions depending on the mode of operation. Please refer to the
chart below to better understand their functionality.
6
