Features

The Agatec RL110 laser offers the interior contractor many great features
to make work easier and more accurate.
A complete laser, with all needed functions, a bright beam for
high visibility, with very compact dimensions.

Laser Overview {A}

See the inside front cover for a diagram of the laser {A} and keypad {B}
corresponding to these callouts.
1) Rotating head
2) Axes indications
3) Plumb or square beam laser beam aperture
4) Rotating laser beam aperture
5) Batteries
6) 5/8"-11 Tripod mount for horizontal setup

Keypad Overview {B}

The keypad for the Agatec RL110 laser has seven buttons and three LED
indicators.
1) On / Off
2) H.I. (Elevation) Alert
3) UP
4) DOWN
5) Rotation Mode
6) Scan
7) Manual Mode
8) LED – H I indication
9) LED – Level Status / Battery
10) LED – Manual mode indication
