Basic Operation

How to use your Agatec RL110/RL110G
Horizontal Setup
The laser can be mounted on a 5/8"-11 tripod or placed directly on a
solid, stable surface. Agatec RL110/RL110G can be suspended from a
ceiling grid using the wall mount (optional).
Vertical Setup
The laser can be placed directly on its back (opposite the handle) on a
solid, stable surface. For more stability, it is recommended to use the wall
mount (optional).
Turning on the laser
Turn on the laser with the On/Off key {B-1}. It does a self-test and the
beam blinks while the laser is self- leveling. After it is leveled, the head
rotates. You can choose H.I. Alert mode or change to manual mode (see
later sections).
The laser has a wide self-leveling range; however, if the laser is set up out
of the leveling range, the laser beam will continue to blink and the
rotation will not start.
LED indication
The LED indicator {B-9} slowly blinks green while the axes are lev-
eling and stays on when both axis has reached a level position.

Button Functions

The UP/DOWN buttons on the laser and the remote control buttons have
multiple functions depending on the mode of operation. Please refer to the
chart below to better understand their functionality.
6
Mode UP / DOWN
Laser buttons and
remote buttons
Automatic mode - Switches to point
rotating mode
Automatic mode - Moves scan
scanning CW/CCW
Laydown mode - Slope
rotating
Laydown mode - Slope
scanning
Manual mode - Slope
rotating
Manual mode - Slope
scanning

Automatic / Manual modes

The Agatec RL110/RL110G is in automatic, self-leveling mode when
turned on. Once the instrument has self-leveled, the laser head will start
rotating with 300 rpm.
In manual mode, the laser does not self-level; this means that the
beam will rotate even if the laser is not leveled. It can therefore be
used on inclined planes such as stairs, roofs, or when manual grade
setting is required. See later section on setting slope in manual or
semi-automatic modes.

H.I. Alert mode

The H.I. feature stops the laser automatically if the laser is disturbed,
preventing inaccurate readings. It functions only when activated.
•
To activate this safeguard feature, keep pressed the H.I. key {B-2} after
turning on the laser. The H.I. LED {B-8} will blink rapidly while the laser
is initializing the H.I. mode.
EN
RIGHT/LEFT
Only Remote Buttons
Cycle through the
rotating speed
Cycle through the
scanning width
Cycle through the
rotating speed
Cycle through the
scanning width
Cycle through the
rotating speed
Cycle through the
scanning width
