• Rotate the laser 180°, allow it to self level and mark the opposite side
of the first axis (Position 2).
• Align the Y-axis by rotating the laser 90° so that this axis is now square
to the wall. Allow the laser to self- level completely, and then mark the
position of the beam (Position 3).
• Rotate the laser 180°, allow it to self level and mark the opposite side
of the Y-axis (Position 4).
• The laser is within its accuracy specification if the four marks are
within ± 3 mm (± 1/8") from the center.

Checking vertical accuracy

To check the vertical accuracy of your laser, place the unit in the laydown
position on a flat, level surface approximately 15-30 meters (50-100 ft.)
from a wall.
• Hang a plumb line on the wall.
• Move the laser until the vertical, rotating beam is aligned to the plumb line.
• If the rotating beam is not plumb, adjustment is necessary.
Adjusting level accuracy -
The X-axis
After checking the accuracy of your laser, perform the following steps to
adjust the accuracy of the X-axis.
Turn off the laser.
• Press and hold the H.I. key {B-2}, then press the ON/OFF key {B-1}.
• After the three LEDs blink three times simultaneously, release the H.I. key.
- The X-axis LED will flash rapidly (red) while leveling
- The X-axis LED will flash slowly (red) when ready for adjustment.
- The head will not be rotating.
- Press the Scan/Rotation key {C-3} to start rotation mode.
