Eterna FLEDB10S Installation Instructions

SPECIFICATIONS:
FLEDB10S
700 lm
nominal useful luminous flux
Rated Wattage 10W
Rated luminous flux 700 lm
nominal life time of the lamp 30,000 hrs
colour temperature 6200K
number of switching cycles
before premature lamp ≥17,500
failure
Warm-up time up to 60 % of
Instant full light
the full light output
Dimmable no
lamp dimensions (mm) 113x85x84
nominal beam angle 120°
Rated power 10W
Rated lamp lifetime 30,000
lamp power factor >0.5
lumen maintenance factor at
≥0.8
end of nominal life
starting time <0.5
colour rendering ≥75
Within 6 step
colour consistency
Macadam ellipse
Rated peak intensity 327cd
Rated beam angle 120°
EvENTUALLy, yOU mAy WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
"WEEE Directive" effective August 2005—UK
WEEE Regulations effective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WhEn yoUR PRoDUcT coMEs To ThE EnD of
ITs lIfE oR yoU choosE To REPlAcE IT, PlEAsE
REcyclE IT WhERE fAcIlITIEs ExIsT - Do noT
DIsPosE WITh hoUsEholD WAsTE.
Issue 2013
FOR PRODUCT ADvICE:
• T: 01933 673 144
• F: 01933 678 083
• E: sales@eterna-lighting.co.uk
FLEDB20 FLEDB30 FLEDB50
1400 lm 2100 lm 3500 lm
20W 30W 50W
1400 lm 2100 lm 3500 lm
30,000 hrs 30,000 hrs 30,000 hrs
6200K 6200K 6200K
≥17,500 ≥17,500 ≥17,500
Instant full light Instant full light Instant full light
no no no
180x140x105 225x183x108 285x235x125
120° 120° 120°
20W 30W 50W
30,000 30,000 30,000
>0.9 >0.9 0.985
≥0.8 ≥0.8 70%
<0.5 <0.5 <0.5
≥75 ≥75 ≥75
Within 6 step Within 6 step Within 6 step
Macadam ellipse Macadam ellipse Macadam ellipse
690cd 1025cd 1569cd
120° 120° 120°
IF yOU ExPERIENCE PROBLEmS:
If you believe your product is defective, please return
it to the place where you bought it. our Technical
Team will gladly advise on any Eterna lighting
product, but may not be able to give specific
instructions regarding individual installations.
Visit our website:
www.eterna-lighting.co.uk
10W
20W
Pack contents:
1 x fitting complete with 3
core 1.0mm x 0.8m silicone
2
cable
FLEDB10S / FLEDB20 / FLEDB30 / FLEDB50
10W, 20W, 30W & 50W Standard LED Floodlights
IP65
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
INSTALLATION INSTRUCTIONS
A guide for qualified electricians
30W
Model:
These instructions are provided as a guideline to assist you.
AND RETAIN FOR FUTURE REFERENCE
50W
