- Page 1 U S E R M A N U A L VELA Tango 100, 100EL, 200 & 200EL VARIANT: Manual no. 105017 VELA Tango 100 Arthrodesis VELA Tango 100 VELA Tango 200 VELA Tango El Sit-stand VELA Tango 100El VELA Tango 200El...
-
Page 2: Table Of Contents
1.4.3. Upholstery 1.5. RECYCLING 1.6. USER MANUAL 1.6.1. Attaching the backrest 1.6.2. Adjustment of seat height (VELA Tango El) 1.6.3. Changing place for height adjustment - right/left armrest or switch box (VELA Tango El) 1.6.4. Adjustment of seat height (VELA Tango) 1.6.5. -
Page 3: Introduction
1.0. INTRODUCTION DEAR CUSTOMER Thank you for purchasing a VELA Tango. This user manual contains useful information about positioning, operating and maintenance of VELA Tango chairs. Important Please read this user manual thoroughly and keep it for later use. This user manual must always accompany the chair. -
Page 4: Safety
8-12, 9200 Aalborg SV, Denmark. means of transportation and should not be used as such. VELA Tango El lives up to all The chair withstands the following EMC-demands according to the IEC transport specifikations: 60601-1-2. -
Page 5: Unpacking The Chair
:: VELA Tango chair 1.5. RECYCLING Several parts of the chair can be re- :: This user manual used. Please return the chair to VELA or to your local recycling center. Note: see section. 1.6.1. for correct mounting of the backrest 1.4. -
Page 6: User Manual
- depending on where the plug is placed (see section 1.6.2.). VELA Note: VELA Tango El is available with remote controlled height TANGO adjustment (i.e. if caregivers must be able to adjust the height). 1.6.3. CHANGING PLACE FOR HEIGHT ADJUSTMENT -... -
Page 7: Adjustment Of Seat Tilt
1.6.5. ADJUSTMENT OF SEAT TILT Adjust the seat tilt by pulling the middle lever placed on your right hand side. 1.6.6. ADJUSTMENT OF BACK ANGLE Adjust the back tilt by pulling the rear lever placed on your right hand side. 1.6.7. -
Page 8: Adjustment Of Armrest, Width
Remember to tighten the handwheel again. 1.6.10. BRAKES VELA Tango brakes by moving the brake lever situated on the side of the frame forward. Unlock the chair by moving the brake lever backwards into upright position. -
Page 9: Back Latch (Vela Tango 200 & 200El)
1.6.13. BACK LATCH (VELA TANGO 200 & 200EL) The backrest can be set to a specific angle by adjusting and secure the the bolt which is mounted on the rear side of the VELA backrest. TANGO VELA 1.6.14. CHARGING (VELA TANGO EL) TANGO Daily charging is recommended. -
Page 10: Foot Plate (Optional)
Adjust the height. Remember to tighten the screw. 1.6.19. FOOTBRAKE PEDAL (OPTIONAL) VELA Tango with footbrake pedal can be used by pressing the top part of the pedal forwards. Unlock the chair by pressing the foot brake back in its original position. -
Page 11: Remote Control (Optional)
Note: insert plug in remote control to operate. 1.6.22. ELECTRIC TILT (OPTIONAL) VELA Tango with electric tilt is adjusted in the right angle via remote control or angle contact. Note: The chair should not be used for transport of persons when the seat is tilted. - Page 12 VELA :: Gøteborgvej 8-12 :: 9200 Aalborg SV :: Denmark :: +45 96 34 76 00 :: mail@vela.dk vela.eu...
