Zavio F611E Quick Installation Manual

Ver 1.1
F611E IP Box Camera
Quick Installation Guide
The Quick Installation Guide provides basic instructions for F611E.
If you need more advanced instructions, please refer to the User's Manual.
www.zavio.com
Surveillance T echnology Innovator

System Requirements

Windows 98, ME, 2000, 2003, XP or Vista
Browser：Internet Explorer 6.0 or above.

Product Feature

MJPEG / MPEG-4 Dual Streaming
Two-way Audio
UPnP
3GPP
External Alarm Input/Output
Front Panel Rear Panel
Body
Audio In/Out
Fixed Iris Lens
Alarm Out
Alarm In
- 1 -
1 .Click "Yes" to initiate the installation
2 .Select the language you want to install, and click "Next".
3 .Click "Next" to start the installation
- 3 -

Check Your Package Contents

F611E IP Box Camera
Power Adapter
Quick Installation Guide
CD-Rom
Lens
Camera Stand

Using the Software CD to configure the camera

Power on your PC and insert the CD-ROM.The setup page should load
automatically. If it does not, please select your CD-ROM drive manually
to open the setup page.
Select "Intelligent IP Installer"
Power adapter
connector
LED Indicator
Reset
Network / PoE connector
4 .If you wish to install the software
program in an alternative location,
click "Browse", otherwise click
"Next" to move on to the next step.
6 .Choose the install options, click
"Next" to proceed.
8 .Click "Finish" to complete the installation.
-2 -
5 .Click "Next" to proceed.
7 .Click "Install" to start the
installation.
- 4 -
