e-ICE User's Guide

e-ICE Introduction

The e-ICE is Holtek's new generation MCU hardware emulator which provides
considerable enhancements over its predecessors. Some features include:

Uses a Real Chip structure to provide simulation results much closer to that of an
actual MCU device

Can setup up to 64K of easily adjusted breakpoints

Simulation hardware can be powered using a variable power supply with a range of
2.2V~5.5V allowing pin voltage levels to be compatible with actual device.

Simplified emulator circuitry, facilitates easier maintenance and greater stability

Uses a USB interface for PC communication with greater ease of use

e-ICE Naming Rules

The e-ICE is comprised of an MEV Board, DEV Board and Peripheral Board. The
following is the naming rules for each part:

MEV Board Part No. Naming Rule
Naming Rules have six digits, e.g. M1001C

DEV Board Part No. Naming Rule
Naming Rules have six digits, e.g. D1001C

Peripheral Board Part No. Naming Rule
Naming Rules have six digits, e.g. P1001B
M 1
type code
D 1
type code
P 1
type code
3
e-ICE User's Guide
001 C
No. version
001 C
No. version
001 B
No. version
