Holtek BC45B4523 Manual

13.56mhz multi-standard nfc reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Features
• Operating Voltage:
Receiver A_V
: 2.7V~3.6V
♦
DD
Transmitter T_V
: 2.7V~5.5V
♦
DD
Digital I/O IO_V
: 2.7V~5.5V
♦
DD
• Operating Temperature: -40°C~85°C
• Power Saving Modes:
Hard Power Down: 0.5μA
♦
Soft Power Down: 4.7μA
♦
Standby: 1.0mA
♦
Support Card Detection mode:
♦
10.4μA @ wakeup period=500ms
• Up to 10Mbps SPI interface speed
• 64-byte send and receive FIFO-buffer
• 64-byte addressing user-configurable registers
• Interrupt pin IRQ
• Programmable timer
• Low jitter on-chip oscillator buffer
• Ultra Low Power On-Chip 3.3V Regulator
• Low Power Card Detection
• External RF Field Detection
• Supported Protocols:
ISO14443A/B, all bit rates
♦
– 106, 212, 424 and 848kbps
ISO15693, all modes
♦
– Downlink: 1 of 4 and 1 of 256
– Uplink: 6.6/13/26/53kbps with 1 sub-carrier
– Uplink: 6.6/13/26kbps with 2 sub-carrier
– Package: 24-pin QFN
Transmitter
• Modulation index adjustable by software
• Output current up to 250mA @ T_V
• Output impedance 3Ω @ T_V
• Arbitrary modulation by external signal
• Wide operating voltage for TX from 2.7V to 5.5V
• On-chip framing coder for supported standards
Receiver
• RX sensitivity down to 2mVp
• On-chip Framing decoder for supported standards
• Automatic Gain Control (AGC)
Rev. 1.20
13.56MHz Multi-Standard NFC Reader
Applications
• Secure access control/door locks
• Toys
• Handheld NFC readers
• Contactless payment system
Abbreviation
AGC: Automatic gain control
CRC: Cyclic redundancy check
DPLL: Digital Phase locked Loop
EGT: Extra guard time in ISO14443B
EOF: End of Frame
ETU: Elementary Time Unit
fc: Carrier frequency
FIFO: First In, First Out Memory
SOF: Start of Frame
UID: Unique Identifier
RF: Radio Frequency
General Description
The BC45B4523 is a single-chip reader ASIC for
13.56MHz NFC/contactless standard protocols,
which provides the best solution for near field
wireless communication applications such as access
control locks, label readers, payment machines.
The device supports and compatibles with all major
global secured baseband ISO standards including
ISO14443 Type A, Type B, Crypto_M cards and
Smart label ISO15693. The device provides a high-
speed SPI controller/host interface with an integrated
64-byte FIFO for smooth data transfer. Furthermore,
=5.0V
the embedded codec is capable of handling all bit-
DD
=5.0V
level coding/decoding, encrypting/decrypting as well
DD
as frame-level manipulation for transmission and
reception. The device is well suited for mobile devices
due to its low power consumption and low operating
voltage from 2.7V to 3.6V. The ultra-low power on-
chip 3.3V regulator is provided to stabilize the device
power, and simultaneously supply power of up to
150mA to the external companion microcontroller.
The BC45B4523 receiver circuit has integrated a full
AGC loop allowing a wide dynamic range of RF input
signal levels. The excellent sensitivity performance of
the device enables detection of the input signals with
1
BC45B4523
October 28, 2020
