TP-Link TL-POE150S Installation Manual

Installation Guide

TL-POE150S (PoE Injector)
TL-POE10R (PoE Splitter)
Some models featured in this guide may be unavailable in your country or region. For local sales information, visit http://www.tp-link.com.
Package Contents: PoE Injector or Splitter, Ethernet Cable, Installation Guide, Power Adapter (for PoE Injector) or Power Cable (for PoE Splitter)
PoE Injector Only
Power Socket
PoE Splitter Only
PoE/PoE+ Switch
PoE Injector & Splitter
Ethernet Device
(switch, router, etc.)
Power Socket
The PoE Injector supplies steady power and data connectivity to a powered device such as PoE IP Camera, PoE
AP and PoE IP Phone through an Ethernet cable.
Ethernet Device
(switch, router, etc.)
The PoE Splitter can be used with a PoE/PoE+ switch to deliver direct current (DC) power and data to a Non-PoE
device.
PoE Splitter
The PoE injector and PoE splitter can be used as a kit to supply power and transmit data to a Non-PoE
device.
PoE Injector
LAN IN
PoE Injector
LAN IN PWR DC 48V
12V 9V 5V
Note:
Set the required voltage
of the non-PoE device
before cable connection.
LAN OUT PWR DC OUT
PoE Splitter
PWR DC 48V LAN OUT DC OUT
PWR
For technical support and other information, please visit
http://www.tp-link.com/support, or simply scan the QR code
Powered Device (PD)
IP Camera AP
Non-PoE Device
(suggested power:＜10W)
Non-PoE Device
(suggested power:＜10W)
12V 9V 5V
Note:
Set the required voltage
of the non-PoE device
before cable connection.
7106506857 REV5.0.0
IP Phone
