- Page 1 User Guide TL-POE10R PoE Splitter Rev:4.0.0 7106503936...
- Page 2 COPYRIGHT & TRADEMARKS Specifications subject change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
- Page 3 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
-
Page 5: Table Of Contents
CONTENTS Package Contents ..............1 Chapter 1 Introduction ............1 Overview of the Product ..........1 Features ..............2 Chapter 2 Identifying External Components..... 2 Chapter 3 Connecting the PoE Splitter ......3 Appendix: Specifications ............ 5... -
Page 6: Package Contents
Chapter 1 Introduction 1.1 Overview of the Product Thank you for choosing the TL-POE10R PoE Splitter. The PoE Splitter fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Injector, such as TP-LINK’s TL-SF1008P or TL-POE150S, to deliver 12V, 9V or 5V Direct Current to the device which do not support PoE. -
Page 7: Features
1.2 Features Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af standards Data and Power carried over the same cable Supports optional 5V DC, 9V DC or 12V DC power supply Supports Plug-and-Play for the devices ， without any configuration Elegant appearance with space-saving mini size Chapter 2 Identifying External Components... -
Page 8: Chapter 3 Connecting The Poe Splitter
PoE Splitter can supply power. Chapter 3 Connecting the PoE Splitter You can use TL-POE10R PoE Splitter with PSE or PoE Injector to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc. - Page 9 3. Connect the LAN OUT port to the Ethernet device with CAT5 UTP cable for data transmitting. 4. Connect the DC OUT port to the power port of the same Ethernet device with the provided power cable. Note: The power of Ethernet device is suggested to be under 10W. Now, the Ethernet device can work normally with data and power.
-
Page 10: Appendix: Specifications
Appendix: Specifications Normal IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Standards IEEE 802.3af, Voltage Output DC 5V, 9V or 12V Power Output 12V/1A, 9V/1A, 5V/2A 1 10/100/1000Mbps Auto-Negotiation RJ45 LAN port 1 10/100/1000Mbps Auto-Negotiation Ports RJ45 PoE port 1 12V/9V/5V DC Power Output Port Cabling Type RJ45 CAT 5 UTP cable Safety &...
