LED Indicators
The LED indicators give you instant feedback on status of the converter:
LED
Power
(per system)
Link/Act/ Speed
(10/100/1000Mbps
port)
Link/Act/ Speed
(Fiber port)
Refer to figure 1 to check the LED location on the front panel.
Color
Status
Light on
Green
Light off
Light on
Green
Blinking
Light on
Amber
Blinking
Light on
Green
Blinking
Light on
Amber
Blinking
figure 1
Description
Power On
Power Off
Connection (or link) at 1000Mbps
Reception or transmission at
1000Mbps
Connection (or link) at 10/100Mbps
Reception or transmission at
10/100Mbps
Connection (or link) at 1000Mbps
Reception or transmission at
1000Mbps
Connection (or link) at 100Mbps
Reception or transmission at
100Mbps
