The front panel LEDs provide instant status feedback, and, helps monitor and
troubleshoot when needed.

Front Panel

There is an array of LED indicators, which provides you with
instant feedback on the status of the power and the fan.

Power and Fan LED

1 / 2
Indicates which the power (fan) is working, depends on
where the power supply was installed at the rear.
Power LED
On (Green)
Off
Power Fail
On (Amber)
LED
Off
Fan Fail LED
On (Amber)
Off
NDICATORS
DMC-1000
Power supply feed in
No power supply feeding
Faulty power supply
Power supply works normally
Faulty Fan
Fan works normally
