PIN-F GREEN
AUX-2
(6 PIN CONN)
PIN-A WHT/GRY
PIN-B WHT/GRN
PIN-C WHT/BU
PIN-D NOT USED
PIN-E BLUE
PIN-F GREEN
FOOT SW.
(3 PIN CONN)
PIN-1 GREEN
PIN-2 WHT/GRN
PIN-3 WHT/ORG
MAIN POWER SW.
PIN-1 NOT USED
PIN-2 BLACK
PIN-3 BLACK
PIN-4 WHITE
PIN-5 NOT USED
PIN-6 NOT USED
MAIN FUSE
PIN-1 BLACK
PIN-2 BLACK
LINE OUT PLUG
WIR-1 BLK WIRE
WIR-2 GREEN
WIR-3 WHITE
OPTICAL TOUCH BUTTON
PLAM BUTTON-2 (LEFT SIDE)
PIN-1 ORG
PIN-2 TAN
PIN-3 WHT/BLK/BRN
PIN-4 GREEN
PALM BUTTOM-1 (RIGHT SIDE)
PIN-1 ORG
PIN-2 GREY
PIN-3 WHT/BLK/GRY
PIN-4 GREEN
OPTICAL PART SENSE/COUNT
SENSER-2 (LEFT SIDE)
PIN-1 ORG
PIN-2 VIO
PIN-3 WHT/VIO
PIN-4 GREEN
SENSER-1 (RIGHT SIDE)
PIN-1 ORG
PIN-2 VIO
PIN-3 WHT/VIO
PIN-4 GREEN
AUX-3 PIN-C, AUX-2 PIN-F, IF/BD J1 PIN-3 OR 4
PLC INPUT PIN-20
IF/BD J1-PIN-3 OR 4, FOOT SW. PIN-3
IF/BD J4-PIN-7
NA
IF/BD J4-PIN-6
IF/BD J1 PIN-3 OR 4, AUX-1 PIN-F, AUX-3 PIN-C
CORCOM STANDOFF
IF/BD J1-PIN-3 OR 4
PLC INPUT PIN-22
NA
FUSE PIN-2
AUX-3 PIN-3, CORCOM LINE (AC), LINE OUT PLUG
PWR CORD, CORCOM LINE (NEU), AUX-3 PIN-G,LINE OUT PLUG
NA
NA
PWR CORD
MAIN POWER SW. PIN-2
MAIN POWER SW. PIN-3
CORCOM CASE GROUND
MAINPOWER SW. PIN-4
(4 PIN MOLEX)
IF/BD J1 PIN-7, PLAM BUTTOM-1 PIN-1
IF/BD J3 PIN-2
IF/BD J3 PIN-1
IF/BD J1 PIN-3 OR 4, PLAM BUTTOM-1 PIN-4
IF/BD J1 PIN-7, PLAM BUTTOM-2 PIN-1
IF/BD J3 PIN-4
IF/BD J3 PIN-3
IF/BD J1 PIN-3 OR 4, PLAM BUTTOM-2 PIN-4
(4PIN MOLEX)
IF/BD J1 PIN-7, SENSER-1 PIN-1
IF/BD J2 PIN-12, SENSER-1 PIN-2
IF/BD J2 PIN-11, SENSER-1 PIN-3
IF/BD J1 PIN-3 OR 4, SENSER-1 PIN-4
IF/BD J1 PIN-7, SENSER-2 PIN-1
IF/BD J2 PIN-12, SENSER-2 PIN-2
IF/BD J2 PIN-11, SENSER-2 PIN-3
IF/BD J1 PIN-3 OR 4, SENSER-2 PIN-4
