The poles numbered 06 and 07 labeled RFL:LED+ and RFL:LED- are pre-connected to a
status indicating LED. Upon powering the system the status LED will turn on and continue
to shine while the system is starting up. When the startup process is completed and the
system is running in normal mode the LED will blink every 4 [sec] ( 2 seconds on and 2
seconds off). In the case that a network connection can't be detected, the LED will blink
every 1 [sec] ( 0.5 seconds on and 0.5 seconds off).
Additionally a reset function is implemented on poles 08 and 09 that are both labeled
RFL:Reset, which should only be temporarily connected when resetting the radar to its
factory settings or setting a fixed IPV4 address.
Connecting the Reset poles for 0.2 to 2 [sec] during operation will cause the sensor to use
the default IPV4 address 192.168.111.71 until the system is rebooted. Connecting the
Reset poles for longer than 10 [sec] during operation will cause the system to reset to
The cable shielding must be connected to ground at both ends of the cable. Since there can
be a potential difference between the ground at the radar and the ground at the processing
unit, a capacitor (10 to 100 [nF]) should be used on one side of the cable between its shield
and the ground.
Improper wiring can damage the radar's communication board. Always check that power
is applied to the right connector before connecting it!
Safety depends on proper grounding of the radar housing. Check the resistance of the
ground connection directly after installation. The measured ground resistance must be
below the maximum prescribed by local grounding requirements.

Closing housing

Make sure that the flange is clean, that the O-ring is in place and not damaged. Then:
• Make sure to properly close the lid.
• Use an 8 [mm] Allen key to tighten the 16 bolts of the housing to a torque of 30 [nm]
or 711 [ft-lbf].
• Open the small cover (cover-A).
• Place the 2 hooks at one end of cover-B behind the axis on the housing and push it
down carefully.
• Push down cover-A carefully.
Note
default factory settings and reboot.
Warning
Warning
