Cables

When selecting a cable for use with a WaveGuide system, the following requirements must
be used:
• Two wires for power transmission. The choice of power supply will influence the
diameter and insulation thickness of those wires.
• Four wires for data transmission. The use of an Ethernet data connection necessitates
the use of four twisted-pair wires (22-24 [AWG] and minimum insulation thickness of
0.245 [mm]).
• The cable must be shielded and can have a maximum length of 80 [m].
Upon request, Radac can supply an optional cable that complies with the WaveGuide
system requirements for power and data transmission.
All connections to the instrument must be made with shielded cables with exception of
the power supply. The shielding must be grounded on both ends of the cable. For more
information regarding wiring and cable specifications.

Glands

Depending on local regulations, this device can be connected by using glands, direct entry,
or conduits
An explosion proof (Ex-d) compound cable gland (M20), plus a M20 to 3/4" NPT converter
are supplied with each WaveGuide radar for use as a safe and watertight cable entry point.
The supplied gland allows the installation of cables from 6.5 to 11.9 [mm] in diameter.
Two approved 3/4" stopping plugs are provided for sealing the unused cable inlets
Instructions supplied by the manufacturer for installing the included cable gland are
The use of Ex-d certified materials of an inappropriate IP value or the improper
installation of cable glands, conduits or stopping plugs will invalidate the Ex approval of
Note
Note
provided separately in its packaging.
Caution
the WaveGuide.
