Labels - RADAC WaveGuide 5 Direction User Manual

Labels

Each processing unit and sensor carry a label indicating product type, model, serial number
as well as product related specifications and certifications. Figures 1.1 and 1.2 illustrate
examples of such labels.
Figure 1.1: Example of WaveGuide 5 Explosion Proof sensor identification label.
Figure 1.2: Example of WaveGuide 5 processing unit identification label located on the bottom side.
WaveGuide Processing Unit
Model: WGPU4000
Nominal power excl. sensors: <4.8Watt
IN: 24-48 VDC, max 2.4A
OUT: V = V , max 0.8A per sensor port
out in
RoHS compliant
Made in the Netherlands
SN:
6
i
www.radac.nl
