WaveGuide processing unit

The RS485 connectors labelled as Sensor 1, Sensor 2 and Sensor 3 are not used in the
COM1
COM2
The connector panel of the WaveGuide processing unit includes the following functional
connectors:
• COM1: Serial port for RS-232 data output.
• COM2: Serial port for RS-232 data output.
• USB: For connecting a USB data storage.
• LAN ports: Ethernet access to the processing unit.
• Input DC: For supplying the processing unit with power (24 to 48 [V]).
• Sensor 1, 2 and 3: Not in use.
WaveGuide 5 Direction system.
Sensor 1
RS 485
RS 485
A
B G
+
nd
RS 232
G
T
R
USB
LAN1
nd
x
x
Figure 2.12: Connector panel on the WaveGuide processing unit.
Note
Sensor 2
RS 485
A
B G
+
A
nd
Input DC
24V - 48V
+
LAN2
18
Sensor 3
B G
+
nd
ON/OFF
