LVDS LCD Panel Connector
LCD/Inverter Power Connector
The system board allows you to connect a LCD Display Panel by means of the LVDS LCD panel
connector and the LCD/Inverter power connector. These connectors transmit video signals and
power from the system board to the LCD Display Panel.
Refer to the right side for the pin functions of these connectors.
BIOS Setting
Configure the LCD panel in the Advanced menu of the BIOS. Refer to Chapter 3 for more in-
formation.
Chapter 2 Hardware Installation
Chapter 2
LVDS LCD Panel Connector
Pin
Pin Name
GND
1
LVDS_CLK-
3
LVDS_Out3-
5
14
LVDS_Out2-
7
LVDS_Out1-
9
LVDS_Out0-
11
1
Panel Power
13
LVDS LCD Panel
5
1
LCD/Inverter power
18
LCD/Inverter Power Connector
Pin
Pin Name
Pin
1
2
GND
2
4
LVDS_CLK+
3
6
LVDS_Out3+
4
LVDS_Out2+
8
5
LVDS_Out1+
10
12
LVDS_Out0+
14
Panel Power
Note:
1. DFI board's LVDS connector:
Manufacturer: E-call
Part No: 0110-3221140
Description: Wafer connector, 14 pin, 1.25mm (pitch), 3.45mm (height), SMT type,
90 degree
2. DFI board's LCD/Inverter power connector:
Manufacturer: E-call
Part No: 0110-3221050
Description: Wafer connector, 5 pin, 1.25mm (pitch), 3.45mm (height), SMT type,
90 degree
Pin Name
+12V
GND
Panel Backlight On/Off Control
Dimming Control
+5V
