Owner's Manual & Assembly Instructions
BP01
Model No.
709241216
Storage Area: 16 Sq. Ft. 98 Cu. Ft.
1,5 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Base
Size
Size
5' x 4'
57" x 45 7/8"
1,4 m x 1,1 m 144,8 cm x 116,5 cm
EH54-A
LM5467
RMW54
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
2,8 m
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
59 1/2"
48"
78"
151,1 cm
121,9 cm
EN54
RM54-A
VL5467
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
Height
54 1/4"
43 1/8"
198,1 cm
137,8 cm 109,5 cm 194,9 cm
HM5467
RMG54
WL54
NW54
RMG54Z
SE5467
RMG54EU
SE5467EU
WL54EU
Door
Opening
Width
Height
76 3/4"
22 1/4"
65"
56,5 cm 165,1 cm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arrow EH54-A
Summary of Contents for Arrow EH54-A
- Page 1 Owner's Manual & Assembly Instructions BP01 Model No. EH54-A EN54 HM5467 LM5467 RM54-A RMG54 RMW54 VL5467 WL54 NW54 RMG54Z SE5467 RMG54EU SE5467EU WL54EU Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests.
- Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
-
Page 3: Customer Service Department
We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available at your local dealer, Arrow's website arrowsheds.com or call Arrow's Customer Service department 1-800-851-1085) or you... -
Page 4: Tools And Materials
PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building. - Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
- Page 6 In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation. Contact Arrow as outlined on the Ordering Accessories page to place an order.
- Page 7 Model No. AT101 Model No. AK100 Heavy-duty galvanized steel bars that New concrete anchor system permits t all 10' (3,0 m) wide Arrow buildings. anchoring any size Arrow building They install quickly and easily to directly to a concrete slab. Each kit...
- Page 8 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis.
- Page 9 OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). If you choose this option Arrow has a simple kit available to provide a oor inside the shed to keep stored items o the ground. This kit can be used to support a plywood oor (wood not included) or be lled with sand/rock to provide a solid surface.
- Page 10 It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
- Page 11 Hardware BP11 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (4) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (35) (Packed with Screws) Bolt (35) Screw (159) 65109 66098 65914...
-
Page 12: Parts List
Parts List BP12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 3719 Door Handle Brace 6300 Vertical Door Brace 6627 Wall Panel 6633 Corner Panel 7044 Corner Panel 10500 Horizontal Door Brace 10473 Door 9725 Rear Wall Angle 9726 Right Roof Panel 9727... - Page 13 Assembly by Key No. BP13...
- Page 14 Step 1 9730 Door Track (1) Parts Needed For 9729 Roof Beam (1) Door Track/Roof Beam Assembly 9731 Roof Beam Angle (1) BP14 The door track assembly supports the sliding door and reinforces the front wall. The roof beam joins the two gables and supports the roof panels.
- Page 15 Step 2 Parts Needed For 9458 Front Floor Frame (1) 8972 Rear Floor Frame (1) Floor Frame 8971 Side Floor Frame (2) BI15 RIGHT REAR 8971 Assemble the four corners of the 8972 oor frame using two screws at each 8971 corner as shown.
- Page 16 Step 3 Parts Needed For 7044 Corner Wall Panel (2) Corners 6633 Corner Wall Panel (2) BI16 STEP NOTE Narrow The remainder of the building assembly Side REAR requires many hours and more than one person. Do not continue beyond this 7044 7044 point if you do not have enough time to...
- Page 17 Step 4 Parts Needed For 9725 Rear Wall Angle (1) 9918 Rear Wall Channel (1) Frames 9919 Side Wall Channel (2) BP17 The main frame pieces give rigidity to the side and rear walls and provide a surface for attaching the gables which support the roof.
- Page 18 9456 Front Wall Panel (1) Step 5 Parts Needed For Door Track Assembly (1) 9698 Door Jamb (1) Panels/Track/Jambs 9370 Door Jamb (1) 6627 Wall Panel (1) BP18 Each wall panel has a crimped rib on one side. The crimped rib should go Plastic Spacer under the rib of the adjacent panel.
- Page 19 9728 Side Wall Angle (2) Step 6 Parts Needed For 9448 Left Gable (2) Angles/Gables/Roof Beam 9449 Right Gable (2) BP19 Roof Beam Assembly (1) STEP The gables go on top of the front and rear walls to support the roof beams. Gable Fasten the side wall angles across the top of the side panels us-...
-
Page 20: Roof Assembly
Step 7 Parts Needed For 9726 Right Roof Panel (2) Roof Assembly 9727 Left Roof Panel (2) BP20 Installing the roof panels is best done NOTE with a step ladder. Begin installing If roof beam holes do not line up with roof panels at the back right corner the roof panel holes, shift the building of the building. - Page 21 Step 8 Parts Needed For 9573 Ridge Cap (1) Ridge Cap/Roof Trim 9574 Side Roof Trim (2) BP21 Install the ridge cap on the com- pleted roof section using bolts and nuts. STEP 9573 Fasten the roof panel rib, peak cap STEP and ridge cap together using bolts Peak Cap...
-
Page 22: Door Assembly
Step 9 3719 Door Handle Brace (1) Parts Needed For 10473 Door (1) Door Assembly 10500 Horizontal Door Brace (2) BI22 6300 Vertical Door Brace (1) The steps on this page tell how to assemble the door. Each bolt and screw in the door requires a washer. - Page 23 Step 10 Parts Needed For Door Assembly (1) 7972 Door Handle Door Installation & Adjustment Lock Bracket (1) BP23 From inside the building, put the Gable bottom of the door assembly (on your Horizontal Door Brace right when you are inside the build- Door Track ing) behind door jamb into the front frame track.
- Page 24 EH54-A EN54 HM5467 LM5467 RM54-A RMG54 RMW54 VL5467 WL54 NW54 RMG54Z SE5467 RMG54EU SE5467EU WL54EU BP24 Anchoring and Floor Frame Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
