AR-B1893A MANUAL
Version 1.1
1. SETTING UP THE SYSTEM
TOP PLACEMENT
Page 1 of 5
BOTTOM PLACEMENT
1.1 SO-DIMM DDR-SDRAM SOCKET 200
PIN (SODIMM1)
1.2 HARD DISK (IDE1 & IDE2) & CF
CONNECTOR (CFD1)
Note: If IDE2 & CFD1 both in used, CFD1 must be as "Master" & IDE2
is as "Slave".
1.3 VGA CONNECTOR
1.4 KEYBOARD / MOUSE CONNECTOR
AR-B1893A Quick Manual
Part NO.
220010141
Advertisement
Related Manuals for Acrosser Technology AR-B1893A
Summary of Contents for Acrosser Technology AR-B1893A
- Page 1 CONNECTOR (CFD1) Note: If IDE2 & CFD1 both in used, CFD1 must be as “Master” & IDE2 is as “Slave”. 1.3 VGA CONNECTOR TOP PLACEMENT 1.4 KEYBOARD / MOUSE CONNECTOR Page 1 of 5 AR-B1893A Quick Manual 220010141 Part NO.
- Page 2 USB3 Pin Header (Port2 & Port3) Note: If CN6 in used, COM2 can’t be used 1.9 FAN CONNECTOR (CPUF1, CPUF2, CPUF3) 1.8 SERIAL PORT COM1: RS-232 1.13 RESET BUTTON 1.10 INTERNAL BUZZER (BZ1) Page 2 of 5 AR-B1893A Quick Manual 220010141 Part NO.
- Page 3 1.14 ATX POWER (ATX1) 1.19 GPIO PORT (CN2) 1.15 MINI PCI SLOT (MPCI1) 1.20 JUMPER & PIN HEADER 1.16 PCI SLOT (PCI1) 1.17 POWER/HD/BYPASS LED (LED5) 1.18 ISP CPLD CONNECTOR (CN1) Page 3 of 5 AR-B1893A Quick Manual 220010141 Part NO.
- Page 4 2.0 WATCH DOG TESTING 2.1 GPIO TESTING 2.2 LCD DISPLAY TESTING Page 4 of 5 AR-B1893A Quick Manual 220010141 Part NO.
-
Page 5: Ethernet Mac Address Programming
(1) b44diag -c 0 -e b44kia -f eeprom.bin -m -T c34 (external loop back cable required). will be prompt to enter MAC address (2) b44diag -c 0 -e b44kia -fmac macaddr.txt Page 5 of 5 AR-B1893A Quick Manual 220010141 Part NO.
