NTP / PTP Services Configuration Window
Use this window to configure NTP reflector and PTP services. See
This page can be used to configure multiple NTPr and PTP configurations.
However, only one timing service can be mapped to each port.
Figure 4-22. NTP / PTP Service Configuration Window
Table 4-8. NTP / PTP Services Configuration Parameters
Parameter / Column
Internal ID
User-defined Name
Service
098-00720-000 Revision D1 – February, 2018
The S6x0 automatically assigns this number as a unique identifier to
reference this specific timing service when it appears on other forms.
The assigned values will not necessarily be consecutive.
Use this entry to provide a helpful name to describe the specific service.
Maximum number of characters in the name is 47.
Although probably not a good idea, multiple rows can have the same entry.
The internal ID assures that they are always unique.
This selection provides a top-level control for the type of network timing
service being defined. The drop-down list provides all candidates.
In release 2.1 the selections are NTPr (NTP reflector), PTP client and PTP
master. See note below about NTPd
Note: These columns are context-aware based on the current Service
column selection. Configure column may be additionally context-aware
based on the selected Profile. Hence the best way to work with these 3
columns (Service, Profile, Configure) is left-to-right.
Description
SyncServer 600 Series User's Guide 105
Chapter 4
Navigation Windows
Figure 4-22.
