Introduction to the R Series
The annunciators and expanders can be mounted on a standard 4-
inch square electrical box, using the included mounting ring. They
can also be surface mounted in locking steel enclosures.
The annunciators communicate with the FACP on the RS-485 data
riser. This can be configured for Class A or Class B communication.
The annunciators do not provide ground fault isolation.
The annunciators are stand-alone units that can be powered by the
FACP or by an approved power supply.
Models with common controls can use a separate, remote key
switch to enable or disable the common controls.
Table 2: R Series models and accessories
Model number Description
RLCD Remote Annunciator: LCD text annunciator
without common controls. English.
RLCD-R Remote Annunciator: LCD text annunciator
without common controls. English. Red.
RLCDF Remote Annunciator: LCD text annunciator
without common controls. French.
RLCD-C Remote Annunciator:LCD text annunciator
with common controls. English.
RLCD-CR Remote Annunciator:LCD text annunciator
with common controls. English. Red.
RLCD-CF Remote Annunciator:LCD text annunciator
with common controls. French.
RLED-C Remote Annunciator: 16-pair LED zone
annunciator with common controls.
English.
RLED-CR Remote Annunciator: 16-pair LED zone
annunciator with common controls.
English. Red.
RLED-CF Remote Annunciator: 16-pair LED zone
annunciator with common controls. French.
RLED24 Remote Expander: 24-pair LED zone
expander with expander cable and zone
card insert.
RLED24R Remote Expander: 24-pair LED zone
expander with expander cable and zone
card insert. Red.
2
Model number
RA-ENC1
RA-ENC2
RA-ENC3
RKEY
RA-LED16ZC
RA-LED24ZC
Part number
27193-16
7300073
7120313-01
7120313-02
R Series Remote Annunciators and Expander Installation and Operation Guide
Description
One-position enclosure for Remote
Annunciator.
Two-position enclosure for Remote
Annunciator and one Remote Expander,
including one interconnection cable.
Three-position enclosure for Remote
Annunciator and two Remote Expanders,
including two interconnection cables.
Remote key switch on plate for enabling or
disabling common controls (Lock/Unlock).
Zone card insert for RLED-C, RLED-CR, and
RLED-CF.
Zone card insert for RLED24, RLED24R.
Description
Electrical box, surface mount, white, single-
gang.
24-inch expander cable assembly, includes
cable and hardware.
12-inch expander cable (cable only).
24-inch expander cable (cable only).
