Introduction to the R Series
The R Series Remote Annunciators and Expander provide remote
annunciation for fire alarm systems. The annunciators offer LCD or
LED annunciation, and can include common controls. The expander
uses LEDs.
The R Series includes three annunciator models and one expander
model. One or two expanders can be connected to any of the
annunciator models. Figure 1 shows the four models in the R Series.
Table 1 lists the features of each model. Table 2 is a complete list of
all models and accessories in the series.
Figure 1: Models in the R Series
RLCD
RLED-C
Table 1: Features of the models
Model
LCD
Display
RLCD, RLCD-R, RLCDF
Yes
RLCD-C, RLCD-CR, RLCD-CF
Yes
RLED-C, RLED-CR, RLED-CF
No
RLED24, RLED24R
No
R Series Remote Annunciators and Expander Installation and Operation Guide
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
Controls Enabled
Ack/Silence
Lamp Test
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
Controls Enabled
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
Zone
Common
System
LEDs
controls
LEDs
No
No
Yes
No
Yes
Yes
16 pairs
Yes
Yes
24 pairs
No
No
Power
Fire Alarm
Supervisory
Ground Fault
Trouble
Controls Enabled
RLCD-C
RLED24
Buzzer
Yes
Yes
Yes
No
Ack/Silence
Reset
Signal Silence
Drill
Lamp Test
1
