Snom D712 User Manual

The Snom 710, D712 and D715 features a four-line black and white graphical display. Under the display
there are four context-sensitive keys and an intuitive, user-friendly menu. On the righthand side, there
are five programmable function keys with built-in LEDs for visual call indication and can be configured
for a variety of one-touch telephony functions such as speed dial, busy lamp field or presence indication.
The Snom 710 and D712 has a 2-port 10/100Mbps Ethernet switch (RJ45) whilst the Snom D715 has a
2 x 1Gigabit Ethernet switch.
Confirms an action, selection, entry
or initiates a call.
Cancels an action, entry or selection
Mute Button
Speaker/ Hands Free Button
ATC EUROPE LTD. NFON GOLD PARTNER 0203-771-2717
The SNOM 710,
D712, D715
Red light indicates missed call
Green light shows one of five
programmable buttons
Toggle key used to select menu options
Message Waiting Light / Voicemail Button
Volume Button. Adjusts receiver or ring tone volume.
Headset Mode
