snom 710, 715, 720, 760 manual
A. General information
1. Introduction
This manual helps you to optimize the usage of the IP telephone in combination with the PBX. Please
use this manual at initial operation. Some features differ from the features described in the
manufacturer's documentation.
The following pages describe the snom 710, 715, 720 and 760 system telephones.
snom 710
snom 715
snom 720
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 715 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snom 715

Summary of Contents for Snom 715

  • Page 1 This manual helps you to optimize the usage of the IP telephone in combination with the PBX. Please use this manual at initial operation. Some features differ from the features described in the manufacturer's documentation. The following pages describe the snom 710, 715, 720 and 760 system telephones. snom 710 snom 715...

  • Page 2: Basic Functions

    760 We wish you success and joy in working with your new telephone and this manual! Subject to alterations. Version 1 / 10.2016 (en) 1. Basic functions 1.1. Overview of keys 1.2. Outgoing call 1.3. Incoming call 1.4. Hold 1.5.

  • Page 3: Initial Setup

    2.1. Overview 2.2. Function keys & codes 2.3. Telephone lock 3. Voicemail 3.1. Initial set-up 3.2. Accessing voicemail 4. IP adress 4.1. How can I find the telephone’s IP address? D. Operation E. Where can you find help with your telephone system? 2.

  • Page 4: Initial Operation

    Using this snom IP telephone with your nfon telephone system merely requires a sound broadband connection. There can be delays with incoming and outgoing calls when using the snom 7xx series in combination with a Plantronics DECT headset and a APU-71 EHS adapter.
  • Page 5 You can activate the function Voice Traffic encryption (SRTP) on the administration portal under ADMINISTRATION / Profile. - Activate the function on the administration portal. - Restart all telephones. Restarting may take a few minutes. During a conversation a lock icon on the telephone display indicates encryption is activated.
  • Page 6 On snom 710, the second function key is by default preconfigured as a menu key. Press this key to enter the phone menu. Once you are in the menu, all Hot Desking settings are the same as on other snom telephones.
  • Page 7 720 Telephone status LED call indicator Display Soft keys Confirm key Navigation key End key VoiceMai key with LED Freely programmable function keys with LEDs DnD key (do not disturb) Phone book key Menu key Transfer key Hold key...
  • Page 8 LED call indicator Not programmable line keys Soft keys Confirm key Navigation key End key VoiceMai key with LED Freely programmable function keys with LEDs DnD key (do not disturb) Phone book key Menu key Transfer key Hold key Microphone for speaker function Headset key with LED Speaker key with LED Volume key...

  • Page 9: Outgoing Call

    Slowly flashing green when the line has a call on hold 3. Voicemail LED: A continuous red light indicates a new message has been saved in voicemail. *The LED indicator of snom 710 flashes solely in green color. 1.2. Outgoing call Note: When dialling an internal telephone number, only the extension needs to be entered.

  • Page 10: Incoming Call

    - Press to select the respective number. You will find the directory key on snom 710 on the upper function key. Please notice that the handling is identical to snom 720/D725 and 760/D765. 1.3. Incoming call There are various options for answering an incoming call:...
  • Page 11 If the party on hold hangs up while on hold, the connection is terminated. Please click on the soft key "Hold" under the display to use "Hold" with snom 710. 1.5. Call waiting and toggling calls If a call comes in while you are on a call, the display shows an icon with a ringing receiver and a double call waiting tone (double beep) can be heard.

  • Page 12: Call Transfer

    , on snom D735 and D785 press the key - To end a 3-way call, press the softkey button „Conf. on“, on snom D735 and D785 press the key Both parties are then placed on “hold” and you can decide whether you wish to continue speaking...

  • Page 13: Accessing Voicemail

    1.8. Accessing voicemail Proceed as follows to retrieve the messages on your mailbox: - Press the voicemail key . It lights up, when you have received a new message. - Enter your voicemail PIN. - Then press 1 to listen to messages. After listening to the message press: 7 to delete 5 to replay the message 6 to go to the next message...
  • Page 14 60 seconds for it to register. The snom 710/D710 does not have a menu key. Access the menu by pressing the the second function key. Refine your call forwarding options via nControl.

  • Page 15: Advanced Telephone Functions

    1.10. Callback The Completion of Calls on No Reply (CCNR) creates a callback in case a person cannot be reached (e.g. the person is not on its desk or busy) at the moment. To use this function, the CCNR function has to be enabled in the administration portal and in the phone extension.
  • Page 16 After pressing the "menu" key you have the following options: Call settings Call waiting indication: define whether this function should be activated. (optional, depending on settings on the administration portal) Timeout: set the ringing time. (optional, depending on settings on the administration portal) Intercom: the intercom function enables speaking directly to a linked extension through the system, without dial tone and ring tone.
  • Page 17 Use the “Toggle key ↑↓” to mark the desired selection and press the Confirm key The snom 710 does not have a menu key. Access the menu by pressing the the second function key. Refine your call forwarding options via Ncontrol.
  • Page 18 Code Description **## Restart devices, only for snom devices! Use outside line "n" to call the telephone number ("n" replaces the “0” otherwise required to access an outside line) Start and end voice recording (if this function is enabled for the...
  • Page 19 *73+nnnn1 Call eFax additional costs will occur *74+nnnn1 Call time control nnnn *75+nnnn1 Call group nnnn *76+nnnn1 Call announcement nnnn *77+nnnn1 Call queue nnnn *78+nnnn1 Call conference service nnnn *791 *791 - Access voice mail for this extension with password *791158 - Access voice mail for extension 158, with the password for 158! *11*791 - Transfer your calls to your voice mail...

  • Page 20: Telephone Lock

    1. Press the “Retrieve” key on the snom telephone itself or by dialing the extension assigned on the service site to access the voice menu of the voicemail system. 2. Then select “0 Mailbox Options” to set up your voice mailbox.
  • Page 21 3. Now press “1” to record a message in the event you are unavailable. 4. Now record your message and press “#” to end the recording. 5. Press “1” to accept the recording, “2” to replay the recording, and “3” to rerecord. 3.2.
