Partlow MRC 7000 Installation & Operation Manual page 23

3.5.2 KEYPAD CONTROLS
The keys on the keypad functions include:
SCROLL: Used to :
UP: Used to:
DOWN: Used to:
AUTO/MAN: Used to:
The upper key is for
Pen 1, the lower key
is for Pen 2 (if provided)
Find Quality Products Online at:
1. Display the enabled modes.
2. While in a mode, used to sequence the parameter codes and
values.
3. Exit some Test and Calibration functions
4. Work in conjunction with other keys:
a. With the UP key to display proportional output %
b. With the DOWN Key;
1) On power up to alter model #
2) Enter Cal/Test functions
1. Exit a mode.
2. Turn a mode On in the Enable mode
3. Increase a parameter numerical value
4. View the setpoint for Pen 1 (Press release)
5. Increase the setpoint value (Press hold)
6. Work in conjunction with other keys:
a. With the SCROLL key to display proportional output %
b. With the DOWN key;
1) Lamp test (Press release)
2) Enter the Enable mode (Press and hold for 11
1. Enter a mode
2. Turn a mode Off in the Enable mode
3. Decrease a parameter numerical value
4. View the setpoint for Pen 2 (if provided)
5. Decrease the setpoint value (Press hold)
6. Step display through parameter codes in a mode
7. Work in conjunction with other keys:
a. With the SCROLL key;
1) On power up to alter the model number
displayed
2) Enter Cal/Test functions
b. With the UP key;
1) Lamp test (Press release)
2) Enter the Enable mode (Press and hold for
1. In the Control mode to enter the Manual mode if proportional
output(s) selected
2. In the Manual mode to enter the Control mode if proportional
output(s) selected
GlobalTestSupply
www.
seconds)
11 seconds)
AUTO
MAN
AUTO
MAN
