Partlow MRC 7000 Installation & Operation Manual page 13

RTD LEAD RESISTANCE
RTD lead length can affect instrument accuracy. Size (gauge) and length of the wire used
affects lead length resistance.
To determine the temperature error resulting from the lead length resistance, use the following
equation:
Terr = TLe * L where; TLe = value from Table 3 if 3 wire or Table 4 is 2 wire.
TABLE 3 3 Wire RTD
Error °C
AWG No.
10 +/-0.04
12 +/-0.07
14 +/-0.10
16 +/-0.16
18 +/-0.26
20 +/-0.41
24 +/-0.65
TABLE 4 2 Wire RTD
Error °C
AWG No.
10 +/-5.32
12 +/-9.31
14 +/-13.3
16 +/-21.3
18 +/-34.6
20 +/-54.5
24 +/-86.5
Example
An application uses 2000 feet of 18 AWG copper lead wire for a 3-wire RTD sensor. What is
the worst-case error due to this leadwire length?
Terr = TLe * L
TLE = +/- .46 (°F/1000 ft) from Table 1
Terr = +/- .46 (°F/1000 ft) * 2000 ft
Terr = +/- 0.92 °F
Find Quality Products Online at:
L = length of leadwire in thousands of feet.
Error °F
+/-0.07
+/-0.11
+/-0.18
+/-0.29
+/-0.46
+/-0.73
+/-1.17
Error °F
+/-9.31
+/-14.6
+/-23.9
+/-38.6
+/-61.2
+/-97.1
+/-155.6
