Anybus X-gateway
Ethernet to J1939 Gateway

User Manual

Part No. AB7665
For Firmware Revision 2.07.01 and Later
Manual Revision 1.20
Doc: HMSI-168-27
Connecting Devices
HALMSTAD • CHICAGO • KARLSRUHE • TOKYO • BEIJING • MILANO • MULHOUSE • COVENTRY • PUNE • COPENHAGEN
HMS Industrial Networks
Mailing address: Box 4126, 300 04 Halmstad, Sweden
E-mail: info@hms-networks.com
Visiting address: Stationsgatan 37, Halmstad, Sweden
www.hms-networks.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J1939 and is the answer not in the manual?

Questions and answers

Related Manuals for HMS J1939

Summary of Contents for HMS J1939

  • Page 1: User Manual

    Anybus X-gateway Ethernet to J1939 Gateway User Manual Part No. AB7665 For Firmware Revision 2.07.01 and Later Manual Revision 1.20 Doc: HMSI-168-27 Connecting Devices HALMSTAD • CHICAGO • KARLSRUHE • TOKYO • BEIJING • MILANO • MULHOUSE • COVENTRY • PUNE • COPENHAGEN...

  • Page 2: Table Of Contents

    Configuration Port Connector........2-5 Configuration ............3-1 Anybus X-gateway Configuration Tool (BWConfig) ... 3-1 Ethernet Network Configuration ......... 3-6 J1939 Network Configuration ........3-15 J1939 I/O Configuration ........... 3-18 Example Application ..........4-1 Scenario #1 - EtherNet/IP .......... 4-1 Ethernet Network Configuration ......... 4-2 J1939 Network Configuration ........
  • Page 3 Table of Contents ii Ethernet Network Configuration ......... 4-7 J1939 Network Configuration ........4-7 J1939 I/O Configuration ..........4-8 EtherNet/IP Interface ..........5-1 Product Features............5-1 CIP Objects ..............5-1 CIP Messaging ............5-2 I/O Messaging ............5-3 Assembly Objects and Connections......5-4 I/O Data Summary .............
  • Page 4 Email Client .............. 9-25 Displaying I/O Data on a Web Page......9-26 Status and Diagnostics........... 10-1 Anybus X-gateway LEDs ......... 10-1 J1939 Status Codes ..........10-4 Diagnostic Web Pages ..........10-5 Status Assembly ............10-5 Specifications ............11-1 Environmental Specifications ........11-1 EMC Directive Compliance ........

  • Page 5: Preface

    The illustrations and samples in this guide are intended solely for the purpose of example. HMS Industrial Networks does not assume responsibility or liability for actual use based upon the examples shown in this publication.

  • Page 6: Related Documentation

    Table 1-1 Related Documentation Modbus/TCP is a trademark of Modbus.org. EtherNet/IP is a trademark of ODVA. Microsoft, MS-DOS, and Windows are trademarks of Microsoft Corporation. Support For technical support, FAQ:s etc, please see www.anybus.com © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 7: Anybus X-Gateway Module Description

    The Anybus Ethernet to J1939 X-gateway allows you to monitor and control data on a J1939 heavy duty vehicle network from an Ethernet device. Data from J1939 messages are mapped to I/O table locations, making them accessible to the Ether- net network.

  • Page 8: Theory Of Operation

    The Anybus X-gateway provides centralized data storage, the “PassageWay ”, for data that is shared between the J1939 and Ethernet networks. Data is placed into the PassageWay by one network interface, allowing the data to be read through the other network interface.

  • Page 9: J1939 Features

    Anybus X-gateway Module Description 1-3 J1939 Features • Transmission and reception of all types of fixed-length J1939 messages, including PDU1, PDU2, broadcast and destination specific. • Monitoring of DM1 (active diagnostics) and DM2 (previously active diagnostics) messages. • Complete network address management including address claim, protec- tion, and yield on higher priority conflict.

  • Page 10: It-Features

    HTML code. This enables the user to access the IN/OUT area using a cus- tomizeable web page interface. • Firmware updates of the X-gateway using the RS232 port and Anybus X- gateway Configuration Tool. • Email client capability. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 11: System Requirements

    DIN rail to mount the X-gateway. Required Software • Anybus X-gateway Configuration Tool software (BWConfig) to config- ure the Anybus X-gateway. • BWConfig requires that the PC be running Microsoft Windows 98, NT, 2000, or XP. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 12: Hardware Description

    On the front of the X-gateway module are 6 LEDs that are used for status indica- tion. These LEDs provide visual status for the overall module, the J1939 interface, and the Ethernet interface. See “Anybus X-gateway LEDs” Page 10-1 for details on how the LEDs are used.

  • Page 13: Installation

    •Terminal tightening torque must be between 5-7 lbs-in (0.5-0.8 Nm). •For use in Class 2 circuits only. •Suitable for surrounding temperature of 65 degrees C maximum. •Use 60/75 C copper wire only. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 14: Power And Network Connections

    The power and network connections to the X-gateway are made on the end of the module. Figure 2-1 indicates the location of each connector. J1939 Power Configuration Ethernet Ethernet IP Address Figure 2-1 Anybus X-gateway Power and Network Connections © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 15: Connecting Power

    24VDC Common 24 VDC + Figure 2-2 Power Connection The X-gateway requires 24 volts DC power. The module will start immediately when power is applied (There is no On/Off switch on the module). © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 16: Connecting J1939

    Installation 2-4 Connecting J1939 The J1939 network connection is a 5-pin terminal block located next to the power connection on the end of the module. The female terminal block connector is pro- vided with the X-gateway. Connections to be made are illustrated in Figure 2-3.

  • Page 17: Connecting To Ethernet

    Note: The Anybus X-gateway does not make use of the modem control signals specified for a DTE connector. Connecting the module through devices, such as isolation modules, which assume control of these lines may cause the BWConfig communications to be unreliable. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 18: Configuration

    Anybus X-gateway Configuration Tool (BWConfig) The Anybus X-gateway Configuration Tool allows you to configure the parame- ters associated with the Ethernet and J1939 network interfaces as well as to set up the contents and layout of the I/O table. BWConfig is a Microsoft Windows application that communicates with a X-gate- way over a standard RS-232 serial link using the PC serial port or USB serial adapter.
  • Page 19 Make sure that the mod- ule is powered and the connection is made, then press the Refresh button on the BWConfig tool bar; this will cause the tool to rescan the serial ports for a module. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 20 Configuration 3-3 BWConfig User Interface The Anybus X-gateway Configuration Tool’s user interface is shown below. Figure 3-1 BWConfig User Interface © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 21 X-gateway module that was detected. Ethernet Configuration Configuration of Ethernet network parame- ters. J1939 Configuration Configuration of J1939 network parameters and status of the network interface. J1939 I/O Configuration Configuration of the content and layout of the I/O tables. Tool Operations The following operations are available through the BWConfig menus and tool bar.
  • Page 22 J1939 I/O configuration. Remove I/O Point Delete the selected input or output data point from the J1939 I/O configuration. Flash Update Perform a field upgrade of the X-gateway module’s firmware. Note: Care should be taken when upgrading firmware, an incomplete update could cause irreparable harm to the module.

  • Page 23: Ethernet Network Configuration

    The speed that the module will communicate 10, 100, or at on the Ethernet network. Auto If the network speed is set to Auto, the module will auto-negotiate network speed. Table 3-1 Ethernet Network Configuration Parameters © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 24 I/O size are not allowed. The I/O size includes any status and command headers as well as the J1939 device data. See “I/O Data Summary” on page 5-9 for details. The actual output assembly size will be 4 bytes less than the I/O size configured.
  • Page 25 Note: The numbers on the switches on the IP configuration DIP switch do NOT correspond to bit locations in the address value. In fact, they are reversed. i.e. bit 0 is set by switch 8. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 26 Subnet mask, and Gateway address is automatically configured by the DHCP/BootP server. It can be enabled using BWConfig or the X-gateway’s Set- tings web page. Note: The use of DHCP is the default configuration for the Anybus X-gateway as shipped. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 27 Switch all 8 switches of the IP Configuration DIP switch to the OFF position to disable the feature. This method can be used to reconfigure a module that has been previously config- ured, or even to reconfigure modules outside the host’s subnet. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 28 Configuration 3-11 Arp/Ping Example: The following commands will set the IP address of a X-gateway with MAC address 00-30-11-02-00-5E to 65.106.34.252. arp -s 65.106.34.252 00-30-11-02-00-5e ping 65.106.34.252 arp -d 65.106.34.252 © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 29 The ethernet addresses can also be configured using the Status and Settings web page resident on the X-gateway. The Status and Settings web page appears as shown below. Figure 3-3 Status and Settings Web Page © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 30 Make sure that the browsers settings are configured to always reload pages. On Internet Explorer this is done in the Temporary Internet Files Settings dialog by selecting the “Every Visit” option for when the browser should check for page changes. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 31 Received? IP = 192.168.1.n IP = 192.168.1.255 Sub = 255.255.255.0 Sub = 255.255.255.0 No Gateway No Gateway Valid Use configuration Configuration from file File? Remain offline Figure 3-4 IP Configuration Initialization Sequence © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 32: J1939 Network Configuration

    Configuration 3-15 J1939 Network Configuration The J1939 network configuration contains the parameters used by the X-gateway for J1939 address management and other network interface options. The parame- ters are described in Table 3-2 below. Refer to Figure 3-1 to see how each param- eter is displayed on the user interface.
  • Page 33 PGN’s configured. See “Offline Detection” Enabled on page 7-14 for a complete discussion. Baud Rate The J1939 baud rate may be set to either 250K 250K or 500K baud. 500K Important: The standard J1939 baud rate is 250K. Do not set the baud rate to...
  • Page 34 Figure 3-5 J1939 Device NAME Dialog The NAME is a 64-bit value that must be unique for every module on a given J1939 network. The meaning and format of the data contained in the NAME value is defined in the J1939-81 specification.

  • Page 35: J1939 I/O Configuration

    J1939 network. The J1939 device output table holds data that is written by a device on the Ether- net network to be transmitted on the J1939 network. Output data points are associ- ated with data of messages that will be transmitted on the J1939 network.
  • Page 36 Configuration 3-19 Data Point Parameters Each data point defines a single piece of data in the either the J1939 device Input or Output table. The data point parameters are organized in columns in the J1939 I/O configuration editor, shown in Figure 3-6. Note that both Input and Output data points have the same parameters with the exception of the message priority;...
  • Page 37 Parameter Description Allowable Range Table Offset The offset into the J1939 device I/O data. If Input: this is an input data point, the offset is into the 0-3999 bits Input data; if this is an output data point, the 0-499 bytes offset is into the Output data.
  • Page 38 Description Allowable Range Priority The J1939 message priority to be used when transmitting this message. If this is an output data point, this is the mes- sage priority that will be used when the mes- sage is produced on the J1939 network.
  • Page 39 2 values separated by a comma or a period will be interpreted as a byte, bit combination. i.e. ‘16’ and ‘2,0’ are equivalent entries. Table 3-3 J1939 I/O Data Point Parameters (Continued) © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
  • Page 40 J1939 Diagnostic Tables The X-gateway has the ability to monitor the commonly used diagnostic messages on J1939. The Active Diagnostics (DM1) and Previously Active Diagnostics (DM2) can be monitored by the X-gateway. Configuring diagnostic table monitor- ing is done through the input data points in much the same manner as data PGN configuration.
  • Page 41 This will automatically be set to 0 Table 3-4 Input Data Point Parameters for Diagnostic Tables Note: See “J1939 Diagnostic Messages” on page 7-9 for details of the format of the diagnostic tables in the J1939 device input data. Note: The J1939 I/O configuration is initialized at X-gateway bootup and when- ever a new configuration is downloaded to the module from BWConfig.

  • Page 42: Example Application

    A system controller (PLC) on EtherNet/IP requires some data that is collected by an ECU and produced on J1939. There is also a piece of data that is determined by the system controller that would be beneficial for some of the ECUs that are on the J1939 network.

  • Page 43: Ethernet Network Configuration

    Refer to “Configuration” on page 3-1 for more details on BWConfig. Figure 4-4 Example J1939 Network Configuration The J1939 device NAME has been set to an arbitrary value for the purpose of this example. The NAME should be set according to the vendor and application where the module is being used based on the J1939 specification.

  • Page 44: J1939 I/O Configuration

    It is desirable to be able to address the 2 values in our example as individual 16-bit words in the EtherNet/IP data. Since the values are packed into 3 bytes in the J1939 message, they need to be parsed out into 2 word locations in the J1939 device input data.
  • Page 45 Notice that the table length has been set to 20 entries. The target address specifies that the diagnostics of the ECM at address 10 are to be monitored by this data point. The diagnostic table will start at byte 100 of the J1939 device input data. © 2014 HMS Industrial Networks AB...
  • Page 46 PGN message, the resulting configuration is quite simple. It is shown in Figure 4- Figure 4-7 Example J1939 Output Configuration The single data point specifies that 2 bytes of data from the beginning of the J1939 device output data is going to be copied into the first 2 bytes of the message. The message will be transmitted with a PGN of 256 and a priority of 6 every 100ms.

  • Page 47: Scenario #2 - Modbus/Tcp

    A system controller (PLC) on Modbus/TCP requires some data that is collected by an ECU on J1939. There is also a piece of data that is determined by the system controller that would be beneficial for some of the ECUs that are on the J1939 net- work.

  • Page 48: Ethernet Network Configuration

    Refer to “Configuration” on page 3-1 for more details on BWConfig. Figure 4-11 Example J1939 Network Configuration The J1939 device NAME has been set to an arbitrary value for the purpose of this example. The NAME should be set according to the vendor and application where the module is being used based on the J1939 specification.

  • Page 49: J1939 I/O Configuration

    The input data points are responsible for determining where in the J1939 device input data the J1939 data is to be placed. It is desirable to be able to address the 2 values in our example as individual registers in Modbus/TCP. Since the values are packed into 3 bytes in the J1939 message, they need to be parsed out into 2 regis- ter locations in the input data.
  • Page 50 ECM at address 10 are to be monitored by this data point. The diagnostic table will start at byte 100 of the J1939 device input data, this will set it at word 50 as desired.
  • Page 51 PGN message, the resulting configuration is quite simple. It is shown in Figure 4- Figure 4-14 Example J1939 Output Configuration The single data point specifies that 2 bytes of data from the beginning of the J1939 device output data is going to be copied into the first 2 bytes of the message. The message will be transmitted with a PGN of 256 and a priority of 6 every 100ms.

  • Page 52: Ethernet/Ip Interface

    Instance. The X- gateway contains the same objects as other modules that are based on the CIP pro- tocol. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 53: Cip Messaging

    Service. The Path is an encoded series of bytes or Segments describ- ing the location of the data item involved in the transfer. The Logical Segment is most often used. It describes the Class, Instance, and Attribute of the data. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...

  • Page 54: I/O Messaging

    The X-gateway allows an EtherNet/IP Scanner access to the I/O data tables. The data received from the J1939 network is collected in the Input Table (IN) of the X- gateway and becomes the EtherNet/IP Input data to the EtherNet/IP scanner. Eth- erNet/IP Output data from the scanner is stored in the X-gateway’s Output Table...

  • Page 55: Assembly Objects And Connections

    I/O assemblies. (see the assembly formats below) If a connection is created with a size larger than the configured I/O data table size, the extra data will be filled with 0. © 2014 HMS Industrial Networks AB Doc: HMSI-168-27...
