Hotel Phone - H2S
Quick Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H2S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fanvil H2S

Summary of Contents for Fanvil H2S

  • Page 1 Hotel Phone - H2S Quick Installation Guide...
  • Page 2 Connection methods Please connect power adapter, network, PC, and handset to the corresponding ports as described in below picture. Wall mount setup Fix the device on the wall. Screw the embedded junction box on the wall  Connect the cable from embedded junction box to the telephone. ...

  • Page 3: Introduction To The Phone User Interface

    Introduction to the Phone User Interface 1.1 Keypad Receiver Ringing Light Hold key Transfer key Standard Telephone Keys Working Light Power Light Redial Volume Control The above picture shows the keypad layout of the device. Each key provides its own specific function. User should refer to the illustration in this section about the usage of each key and the description in this document about each function.

  • Page 4: Phone Settings

    Phone Settings In order to get the device ready for making and receiving phone calls, the device must be configured with correct network configurations and with an SIP telephony service. The SIP must be configured properly to be able to provide telephony service. 2.1 Getting IP address DHCP is the default setting in Network, and telephone will get the IP address from DHCP server(Router) after the line connected.

  • Page 5: Sip Setting

    2.4 SIP Setting Enter into the web setting interface, select Line->SIP, and fill in the items below. Server Address  Account Name  Phone Number  Password  Click the Apply button to save the Configuration, that you can make a call after the SIP registration is successful.

  • Page 6: 3 Basic Operation

    Basic Operation 3.1 Making call There using dial pad to make a call. Lift the handset.  Dial the number on the dial pad, end with # as default.  End a call, hang up handset.  3.2 Answering call When your telephone rings and the light flashes.
