Advanced Poly-Packaging T-1000 Operation Manual page 125

ITEM NO. QTY.
1 1
2 1
2 1
2 1
2 1
3 1
3 1
3 1
3 1
4 1
5 2
6 2
7 2
8 2
9 2
10 1
11 1
12 3
13 1
14 2
15 2
16 2
17 2
18 4
19 2
20 1
21 1
22 1
23 2
23 2
23 2
23 2
24 1
25 1
26 1
26 1
26 1
26 1
27 1
28 2
Sealer Frame Assembly
PN: TA-T10280-S14
Part No
TP-T1MB00200
TP-T1MD000276
TP- T1MD00276NB-1
TP-T1MD000276-2
TP-T1MD000276-3
TP-T1MD000275
TP- T1MD00275NB-1
TP-T1MD000275-2
TP-T1MD000275-3
TP- T1MD00277NB
TP-402186
TP-107127-1
TP-401277
TP-403245
TP-T1MB00057
TA-T10009
TA-T10006
TP-211374
TP-T1MB00164
TP-101132
TP-107228
TP-107227
TP-401257
TP-107160
TP- T1MB00027
TP- T1MB00005
TP-T1MB00107
TP-102254
TP-T1MB00033
TP-T1MB00033-1
TP-T1MB00033-2
TP-T1MB00033-3
TA-T10005
TP-T1MB00010
TP-403244
TP-403146
TP-403242
TP-403241
TP-T1MB00016
TP-T1MB00022
:
Drop Frame
DESCRIPTION
SEALER FRAME
NBO INTERNAL GUARD (4.25" PASS-THROUGH)
NBO INTERNAL GUARD (5.25" PASS-THROUGH)
NBO INTERNAL GUARD (6.25" PASS-THROUGH)
NBO INTERNAL GUARD (7.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (4.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (5.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (6.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (7.25" PASS-THROUGH)
SHORT INTERNAL GUARD
FLOW CONTROL, #10-32
BRONZE BUSHING
ELBOW, 1/4 TUBE
AIR CYLINDER
HEATER BAR YOKE
TEFLON GUIDE SUB-ASSEMBLY
HEATER BAR SUB-ASSEMBLY
MAGNET, ROUND
PIVOT CLAMP
NUT, ACORN 5/16-18
BUSHING, NYLON FLANGE
BUSHING, THRUST NYLON
ELBOW, 1/4" TUBE x 1/8 NPT
TEFLON COATED BUSHING
GRIPPER SPACER
FRONT GRIPPER PLATE
MAGNETIC SENSOR HOUSING
WASHER, FENDER
SEAL GUIDE ROD (4.25" Pass-Through)
SEAL GUIDE ROD (5.25" Pass-Through)
SEAL GUIDE ROD (6.25" Pass-Through)
SEAL GUIDE ROD (7.25" Pass-Through)
PRESSURE BAR SUB ASSEMBLY
SEALER ROD TIE
CYLINDER (4.25" Pass-Through)
CYLINDER (5.25" Pass-Through)
CYLINDER (6.25" Pass-Through)
CYLINDER (7.25" Pass-Through)
SEAL CYLINDER MOUNTING BLOCK
GUARD ROD MOUNTING BLOCK
